Self-Adhesive Strip - Intermec EasyCoder F4 Installation & Operation Manual

Media, cont.

Self-Adhesive Strip

Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
⇐ a ⇒ Media Width (including liner):
Maximum:
Minimum (standard):
Minimum (narrow Quick-Load):
Minimum (wide Quick-Load):
⇐ b ⇒ Liner
The liner must not extend more than a total of 1.6 mm (0.06
inches) outside the face material and should protrude equally
on both sides.
⇐ c ⇒ Media Width (excluding liner):
Maximum:
Minimum:
Media Type Setup:
• Continuous
Appendix 2 Media Specifi cations
114.3 mm (4.50 inches)
25.0 mm (1.00 inches)
40.0 mm (1.57 inches)
80.0 mm (3.15 inches)
112.7 mm (4.43 inches)
23.8 mm (0.94 inches)
67
