Intermec EasyCoder F4 Installation & Operation Manual page 33

Chapter 5 Ribbon Load
Ribbon Load, cont.
3
In case of ribbon reload, remove any used
ribbon and empty ribbon core.
5
Slide the ribbon roll onto the supply hub so the
ink-coated side faces down when the ribbon is
routed through the print mechanism.
32
4
Unpack a roll of original Intermec thermal
6
Route the ribbon through the print mechanism
and pull out approximately 20 cm (8 inches)
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
transfer ribbon.
of ribbon.
