Peel-Off (Self-Strip) - Intermec EasyCoder F4 Installation & Operation Manual

Chapter 4 Media Load
Peel-Off
(Self-strip)
Important!
Save the label indicating the
sensitivity number attached to
the media roll. You will need
this number to set the media
sensitivity, see Appendix 2.
1
Open the side door.
26
The EasyCoder F4 can print on labels, tickets, tags, and continuous
stock in various forms. This chapter describes the case when
self-adhesive labels are separated from the liner immediately after
printing. The liner is then wound up on an integral liner takeup hub.
This is also known as "Self-strip" operation.
Peel-off operation cannot be performed when Quick-Load guides
are fi tted.
Peel-off can only be used for:
• Self-adhesive labels with liner
An optional label taken sensor can hold the printing of next label
in a batch until the present label has been removed, see Chapter
8, "Options."
2
Turn the printhead lift lever clockwise to raise
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
the printhead.
