Introduction - Intermec EasyCoder F4 Installation & Operation Manual

Chapter 8
Options

Introduction

Label Taken
Sensor
Short Side Door
Long Side Door
Transfer Ribbon
Mechanism
Long Side Door
w. 8-inch Megatop
46
The EasyCoder F4 is designed to provide a high degree of fl exibility
because it has a modular design. By adding options to the basic
printer, the EasyCoder F4 can be adapted for a variety of applications.
Most options can easily be installed by the operator, however, a few
should be installed by an authorized service technician or are only
available as factory-installed options.
Narrow Quick-Load Guides
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
Covers
(used when a transfer ribbon
mechanism or liner takeup is
not fi tted)
Wide Quick-Load Guides
1.5-inch Rotating
Supply Hub
Supply Roll
Post
3-inch Adapter
Liner Takeup
and Guide
Shaft
