Chapter 8 Options
Quick-Load
Guides
Label Taken
Sensor
Interface Boards
48
For Quick-Load operation (see Chapter 4, "Media Load"), a set of
wide or narrow Quick-Load guides is installed at the rear of the print
mechanism instead of the standard edge guide. The outer guide is
adjustable for different media widths. Two sets of Quick-Load guides
are included as standard in the delivery (either factory-fi tted or
loose). They can easily be installed by the operator:
1. Open the upper media guide (see illustration in Chapter 10,
"Maintenance/Cleaning the Media Guides.")
2. Pull out the standard edge guide from the shaft.
3. Fit the appropriate set of Quick-Load guides onto the shaft as
illustrated on the fi rst page of this chapter.
The Label Taken Sensor (LTS) is a photoelectric sensor, which
enables the printer's fi rmware to detect if the latest printed label,
ticket, tag etc. has been removed before printing another copy.
A number of different interface boards are available for use with the
EasyCoder F4. The interface boards are either factory fi tted or can
easily be fi tted by an authorized service technician.
The EasyCoder F4 can accommodate one interface board.
The IPL version of the EasyCoder F4 only supports one of these
interface boards:
• IEEE 1284 Parallel Interface Board
Refer to Appendix 3, "Interfaces" for more information.
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
