Kongsberg Simrad ES80 Manuals
Manuals and User Guides for Kongsberg Simrad ES80. We have
2
Kongsberg Simrad ES80 manuals available for free PDF download: Installation Manual, Instruction Manual
Kongsberg Simrad ES80 Installation Manual (312 pages)
Brand:
Kongsberg
| Category:
Marine Equipment
| Size: 27.82 MB
Table of Contents
Table of Contents
5
About this Manual
11
Simrad Es80
13
Important
14
System Description
15
System Diagram
18
Main System Units
19
Display Description
19
Processor Unit Description
20
Ethernet Switch Description
21
Wideband Transceiver (WBT) Description
21
Transducers
22
Scope of Supply
23
Basic Items Provided with a Standard Delivery
23
Additional Required Items
26
Additional Optional Items
29
General Safety Rules
34
Installation Requirements
35
Supply Voltage Requirements
35
Uninterruptible Power Supply (UPS) Requirements
35
Cables and Wiring Requirements
36
Compass Deviation Requirements
36
Noise Sources
37
Dry Docking Requirements
38
Requirement for Classification Approval
38
Network Security
39
Support Information
40
Preparations
43
Installation Summary
44
About Installation Drawings
46
Tools, Equipment and Consumables Required for ES80 Installation
46
Personnel Qualifications
47
Where to Install the Transducer
48
Mount the Transducer Deep
48
Avoid Protruding Objects Near the Transducer
49
Mount the Transducer at Forward Part of Hull to Minimize the Effects from the Flow Boundary Water Layer
50
Keep the Transducer Far Away from the Propellers
51
Mount the Transducer at a Safe Distance from Bow Thruster(S)
51
Summary and General Recommendations
53
Acoustic Noise
55
Contributing Factors
55
Self Noise
57
Ambient Noise
60
Fishing Gear Noise
60
Electrical Self Noise
61
Some Means to Reduce Acoustic Noise
61
Vessel Coordinate System
63
Installing the Es80 Hardware Units
66
Installing the Wideband Transceiver (WBT) Using the Integrated Brackets
67
Installing the Wideband Transceiver (WBT) in a 19" Rack
69
Installing the WBT Power Supply
71
Installing the Display
73
Installing the CEHW Processor Unit
74
Installing a Commercial Computer
76
Installing the Ethernet Switch
78
Installing the Transducer(S)
79
Cable Layout and Interconnections
81
Read this First
82
Reducing Electrical Noise
82
Cable Plans
84
About the Cable Plans
84
Topside Cable Plan
85
Sonar Room Cable Plan with One Transceiver
87
Sonar Room Cable Plan with Two Transceivers
88
List of ES80 Cables
89
Installing the ES80 Cables
91
Prerequisites for Cable Installation
91
Installing the ES80 Topside Cables
92
Installing the Wideband Transceiver (WBT) Cables
94
Connectors on the Nexcom Processor Unit
96
Connectors on the CEHW Processor Unit
98
Wideband Transceiver (WBT) Connectors
101
Using a Steel Conduit to Protect the Transducer Cable
102
Splicing the Transducer Cable
104
Setting up the ES80 in a Synchronized System
107
About Synchronization
107
Synchronization Modes
108
Synchronization Sequences
109
Synchronization Using Clear to Send (CTS) and Request to Send (RTS) Signals
110
Synchronization Using the Auxiliary Socket on the Transceiver
111
Synchronizing the ES80 by Means of a Serial Port
112
Synchronizing the ES80 by Means of the Auxiliary Port
115
Cable Drawings and Specifications
118
AC Power Cable Using IEC C13 Inline Socket
119
Ground Cable
121
RS-232 Serial Line Connection Using Three Wires
122
RS-232 Serial Line Connection Using Five Wires
123
CEHW03 RS-232 Serial Line Connection Using Three Wires
124
CEHW03 RS-422 Serial Line Connection Using Five Wires
125
Used as Synchronization Trigger (Input or Output)
126
RJ45 High Speed Ethernet Cable (1000Base-T)
127
Battery Power Cable
128
K-Sync Interface to Generic RS-232 Synchronization Input
129
Simrad TU40 Interface to Generic RS-232 Synchronization Input
131
Auxiliary Connector for Synchronization
133
Single Beam Low Power Transducer Connection to a Circular Transducer Socket
134
Split Beam Transducer Connection to an Amphenol Socket
135
Split Beam Transducer Connection for Single Beam Use on an Amphenol Socket
139
About Serial Lines
142
Basic Cable Requirements
145
Cable Trays
145
Radio Frequency Interference
146
Physical Protection of Cables
147
Grounding of System Cables
147
Cable Connections and Terminations
148
Cable Identification
148
Cable Glands and Termination Procedures
149
Setting to Work
155
Setting to Work Summary
156
Making Sure that the ES80 Is Ready for Operational Use
158
Making Sure that the AC Mains Supply Voltage Is Correct
158
Making Sure that All ES80 Cables Are Properly Connected
159
Visual Inspection of the Display
160
Visual Inspection of the Processor Unit
162
Visual Inspection of the Wideband Transceiver (WBT)
164
Turning on the ES80 for the First Time
166
Setting up Summary
166
Installing the ES80 Operational Software
168
Turning on the ES80 to Passive Mode
169
Obtaining and Installing the Software License
170
Defining the IP Address on the Processor Unit Network Adapter for Communication with the Wideband Transceiver (WBT)
172
Installing One or more Transducers
173
Installing Transceiver Channels
176
Adjusting the Screen Resolution
179
Restoring Correct Scaling of the ES80 Presentation
180
Configuring the ES80 for Normal Operation
182
Selecting Menu Language
182
Selecting Measurement Units
183
Defining the File and Folder Settings for Data Recording
184
Placing each Sensor in the Vessel Coordinate System
186
Dimensional Surveying
186
Surveying the Transducer and the Navigation Sensors
187
Example Procedure
188
Vessel Coordinate System
191
Interfacing Peripheral Equipment
194
Installing Navigation Sensors and Other Sensors
194
Defining the Serial and Ethernet (LAN) Port Parameters
196
Setting up the Input from a Navigation System (GPS)
197
Configuring the Sensor Interface
200
Setting up a Serial or LAN (Ethernet) Port for Annotation Input
202
Connecting a Catch Monitoring System to a Serial or LAN (Ethernet) Port
204
Connecting a Trawl System to a Serial or LAN (Ethernet) Port
206
Setting up the Input from a Motion Reference Unit (MRU)
208
Setting up Depth Output to an External System
210
Exporting Sensor Data to a Peripheral System
213
Setting up Data Export to Olex
215
Synchronizing the ES80 by Means of a Serial Port
217
Synchronizing the ES80 by Means of the Auxiliary Port
220
Test Procedures
223
Functional Test of the ES80 Wideband Fish Finding Echo Sounder
224
Measuring Noise in Passive Operating Mode
226
Reading the Transceiver Hardware and Software Versions
229
Verifying the Communication with the Course Gyro
230
Verifying the Communication with a Navigation System (GPS)
232
Verifying the Communication with Speed Log
235
Verifying the Communication with the Motion Reference Unit (MRU)
237
Verifying the Communication with a Synchronization System
239
Making a Noise/Speed Curve to Determine Vessel Noise
241
Turning off the ES80
245
Installation Remarks
246
Technical Specifications
247
Introduction to Technical Specifications
248
Interface Specifications
249
Supported Datagram Formats for Annotation Data
249
Supported Datagram Formats for Distance Information
250
Supported Datagram Formats for Drop Keel Offset Information
250
Supported Datagram Formats for Position Information
251
Supported Datagram Formats for Heading and Gyro Information
252
Supported Datagram Formats for Trawl Information
252
Supported Datagram Formats for Motion Information
253
Supported Datagram Formats for Palette Control
254
Supported Datagram Formats for Catch Monitoring Information
254
Supported Datagram Formats for Speed Log Information
255
Supported Datagram Formats for Temperature Information
256
Supported Datagram Formats for Water Level Offset Information
256
Supported Datagram Formats for Depth Information
257
Weights and Outline Dimensions
258
Display Weight and Outline Dimensions
258
CEHW03 Processor Unit Weight and Outline Dimensions
258
Wide Band Transceiver (WBT) Weight and Outline Dimensions
259
LBG408A-R2 Ethernet Switch Weight and Outline Dimensions
259
Power Requirements
261
Display Power Requirements
261
CEHW03 Processor Unit Power Requirements
261
Wide Band Transceiver (WBT) Power Requirements
262
WBT Power Supply Power Requirements
262
LBG408A-R2 Ethernet Switch Power Requirements
263
Environmental Requirements
264
Display Environmental Requirements
264
CEHW03 Processor Unit Environmental Requirements
264
Wide Band Transceiver (WBT) Environmental Requirements
265
LBG408A-R2 Ethernet Switch Environmental Requirements
265
Compass Safe Distance
267
Display Compass Safe Distance
267
CEHW03 Processor Unit Compass Safe Distance
267
Wide Band Transceiver (WBT) Compass Safe Distance
268
WBT Power Supply Compass Safe Distance
268
LBG408A-R2 Ethernet Switch Compass Safe Distance
268
Minimum Computer Requirements
269
Minimum Display Requirements
270
Drawing File
272
About the Drawings in the Drawing File
273
388697 Wideband Transceiver (WBT) Outline Dimensions
274
447219 CEHW03 Processor Unit Dimensions
276
201575 Transducer Connector Assembly and Wiring
278
Equipment Handling
280
Transporting Kongsberg Maritime Equipment
281
Lifting Units and Transportation Boxes
282
Inspection of Units and Transportation Boxes after Arrival
283
Specifications for Storage Prior to Installation or Use
284
Unpacking Instructions
285
Unpacking Standard Parts and Units
286
Unpacking Mechanical Units
287
Unpacking Electronic and Electromechanical Units
288
Unpacking Transducers
289
Specifications for Storage after Unpacking
290
Advertisement
Kongsberg Simrad ES80 Instruction Manual (42 pages)
Brand:
Kongsberg
| Category:
Marine Equipment
| Size: 0.95 MB
Table of Contents
Table of Contents
3
About this Manual
5
Introduction
7
About Current Indicator Calibration
7
Calibration Summary
8
Support Information
9
Preparations
12
Calibrating the Current Indicator
12
Obtaining and Installing the Software License for Raw Data Recording
14
Selecting the Location for Current Indicator Calibration
15
Configuring the Environmental Parameters
16
Importing the Water Temperature from the Transducer
17
Configuring the Sensor Priority for Current Indicator Calibration
18
Inserting the Installation Parameters for the Global Positioning System (GPS) Antenna and the Transducer
20
Defining the File and Folder Settings for Raw Data Recording
23
Defining the Bottom Detection Parameters for the Calibration
24
Preparing the Echo Sounder System for Current Indicator Calibration
26
Calibrating the Current Velocity Measurements
28
Recording Raw Data
28
Collecting Data for Current Indicator Calibration
29
Processing Data for Current Indicator Calibration
33
Functions and Dialog Boxes
35
Calibration Function
35
Calibration Wizard Dialog Box #1
36
Calibration Wizard Dialog Box #2
37
Calibration Wizard Dialog Box #3
38
Advertisement
Related Products
Kongsberg EM - REV M
Kongsberg EN 250 - DATASHEET REV C
Kongsberg EM series
Kongsberg EM 712
Kongsberg EA 400
Kongsberg EM 2000
Kongsberg EM 1002
Kongsberg EM 710
Kongsberg EM 122
Kongsberg EM 950
Kongsberg Categories
Marine Equipment
Sonar
Marine Radio
Transceiver
Radio
More Kongsberg Manuals
Login
Sign In
OR
Sign in with Facebook
Sign in with Google
Upload manual
Upload from disk
Upload from URL
