60
the clip will remain unchanged. For more information, see
View"
¡ Important This option is for preview only. You should clear it before you
render your clip, otherwise the split will appear in your video output.
• Proc Amps The processing amplifier (proc amp) controls allow you to
adjust different aspects of your clip:
$
$
$
$
• RGB Curves Lets you use curves to adjust the red, green, and blue color
channels of your clip individually, or use a master curve to adjust all color
channels simultaneously. For more information, see
page 63.
• Color Balance These controls let you adjust the mixture of colors in your
clip.
$
$
$
• Luma Mapping
$
Chapter 4, Setting Up Realtime Effects with Adobe Premiere Pro
on page 61.
Adjusts the tint of the colors in the image.
Hue
Saturation Adjusts the saturation (vividness) of the image's colors.
Adjusts the difference in luminance between the lightest and
Contrast
darkest areas of the image.
Brightness Adjusts the level of black in the image.
Allows you to fine-tune the tonal ranges of your clip by
Tonal Range
reducing the range of pixels included for shadows, midtones, or highlights.
For more information, see
Graphical Allows you to see a graphical representation of your changes
when you adjust the color balance settings. You can also modify most of
the color balance settings directly within the graph. For more information,
see "Using the color balance graph"
Numerical Lets you adjust your color balance settings numerically by
entering values in the text boxes, or by dragging the corresponding sliders.
You can adjust the Hue , Saturation , and Luminance for each tonal range.
Master (Hue , Saturation , and Luminance) Affects all areas of your
•
clip from the lightest white to the darkest black.
Shadows (Hue , Saturation , and Luminance) Affects the darkest
•
areas of your clip.
Midtones (Hue , Saturation , and Luminance) Affects the areas with
•
tones between the darkest and lightest areas of your clip.
Highlights (Hue , Saturation , and Luminance) Affects the lightest
•
areas of your clip.
Graphical Allows you to see a graphical representation of your changes
when you adjust the luma mapping settings. You can also modify the
"Adjusting tonal range"
on page 66.
"Using Split
"Using RGB curves"
on page 65.
on
