MPEG-2 I-frame HD codec workflow example
for online editing
In this workflow example, the Matrox MPEG-2 I-frame HD codec is used to
capture video clips for use in an online editing project. The clips are captured
with Matrox RT.X2 at a data rate of 90 Mb/sec or higher and then used to
complete an online editing project. A VFW application, such as Adobe After
Effects, is used to create a composition that is rendered using the VFW MPEG-2
I-frame HD codec and imported into the online editing project. When the edit is
complete, it is exported to tape for broadcast.
This workflow scenario is represented in the following diagram:
Analog component video
footage shot as 1080i @
29.97 fps or 25 fps
Matrox MPEG-2 I-frame HD codec
set at 90 Mb/sec or higher used to
capture clips
Matrox online editing project using
a 1440x1080i MPEG-2 I-frame
project preset
Exported to tape as finishing-quality
HD video for broadcast
MPEG-2 I-frame HD clips used
in a VFW application on the
RT.X2 system or an offline
editing station.
Clips rendered using
the Matrox VFW
MPEG-2 I-frame HD
codec are imported into
the online editing
project.
Using the Matrox MPEG-2 I-frame HD codec
VFW application, such as
Adobe After Effects, uses
the MPEG-2 I-frame HD
clips. The compositing
project is rendered using
the Matrox VFW MPEG-2
I-frame HD codec.
185
