Section

Programmable key functions

You can assign the functions described below to [Top],
[Upper], and [Lower] by using the CS-F29DR
(purchase separately).
software
Ask your dealer for details.
NOTE: See the instruction manual that comes with
the transceiver for the default settings of these keys.
Null
➥ No function is assigned.
ZONE
➥ Push to toggle the operating Zone.
• E ach time the user pushes this key, the transceiver
selects Zone 1, Zone 2, and then Zone 1 again.
SCAN
NOTE:
Select the channels to be scanned by using
CS-F29DR
cloning software
➥ Push to start or pause a scan.
• W hen a scan is started with the Power ON Scan or the
Automatic scan function, push this key to pause the
scan. The paused scan resumes after a set time period.
➥ Hold down this key while a scan is paused, and
then the channel is removed from the scan group.
• T he removed channel is automatically added to the
scan group again, after the scan is canceled.
MONI
➥ While holding down this key, the C.Tone* mute
is released, even if the received signal does not
include a matching C.Tone*.
* CTCSS tone or DTCS code
PROGRAMMABLE KEY FUNCTIONS
cloning
.
[Rotary Selector]
[PTT]
[Upper]
[Lower]
LOCK
➥ Hold down to turn the Key Lock function ON or
OFF.
• E ven when the Key Lock function is ON, [PTT], [MONI],
[LOCK], [CALL], [CLEAR], [SURVEILLANCE], and
[SIREN] are not locked.
CALL // only on a Digital channel //
➥ Push to make a call that includes a Common ID.
CLEAR // only on a Digital channel //
➥ P ush to finish a communication by sending a clear
down signal. After the other station receives the
clear down signal, the transceiver automatically
enters to the Stand-by mode.
BREAK // only on a Digital channel //
➥ Hold down to send a Break-in request call.
• T he Break-in request call announces to the other
stations on the channel that the user wants to break into
the current communication in the group. The transceiver
waits for the current communication to end. After the
communication ends, the transceiver automatically
sends the call.
➥ While waiting, push this key to cancel the Break-in
request call.
S-RING/C-RING
// only on an Analog channel //
➥ Push to make a Smart-Ring call.
// on both an Analog and a Digital channel //
➥ Hold down to make a Call-Ring call.
3
[VOL]
[Top]
