Icom IC-M603 Instruction Manual page 14

3
BASIC OPERATION
D International channels
There are pre-programmed 57 international channels for the
IC-M603.
q Push [DIAL] to select a regular channel.
w While pushing and holding [H/L], push [DIAL] to change
the channel group, if necessary.
• "INT" appears when International channel is selected.
e Rotate [SELECTOR] to select a channel.
• "DUP" appears for duplex channels.
• Pushing the keypad or [Y]/[Z] on the microphone also selects
a channel.
Push +
H/L DIAL
D U.S.A. channels
For U.K. version, there are pre-programmed 61 U.S.A. chan-
nels in addition to 59 International channels.
q Push [DIAL] to select a regular channel.
w While pushing and holding [H/L], push [DIAL] to change
the channel group, if necessary.
• International and U.S.A. channels can be selected in sequence.
e Rotate [SELECTOR] to select a channel.
• "DUP" appears for duplex channels.
• Pushing the keypad or [Y]/[Z] on the microphone also selects
a channel.
8
25W USA
DUP
TAG
34°34.506N
123°23.236W
UTC 12:00 PORT OPR
(U.K. version only)
Push +
H/L DIAL
D ATIS and DSC channels
For Holland and FRG version, there are pre-programmed 57
ATIS and 57 DSC* channels in addition to 58
or 56 International channels.
(FRG version)
*FRG version only
q Push [DIAL] to select a regular channel.
w While pushing and holding [H/L], push [DIAL] to change
the channel group, if necessary.
• International, ATIS and DSC channels can be selected in se-
quence.
e Rotate [SELECTOR] to select a channel.
• "DUP" appears for duplex channels.
• Pushing the keypad or [Y]/[Z] on the microphone also selects
a channel.
Push
H/L
1W ATIS
COMMERCIAL
ATIS channel
25W INT
DUP
TAG
34°34.506N
123°23.236W
UTC 12:00 PORT OPR
(Holland and FRG versions only)
(Holland version)
+
DIAL
25W DSC
TAG
34°34.506N
123°23.236W
UTC 12:00 CALLING
DSC channel
