ADTRAN NetVanta 7100 Basic Installation And Call Handling page 9

CYCLE POWER OF PoE PORTS
The ADTRAN and Polycom SIP based phones load configuration files at boot. If the
voice user was created after the phone had already been plugged in, removing power to the
port that the phone is connected to is one way to force the IP phone to reboot.
10. Navigate to the Data / Switch / Power over Ethernet screen.
11. Cycle the power of Eth 0/1 and Eth 0/2 from AUTO to OFF.
12. Cycle the power of Eth 0/1 and Eth 0/2 from OFF to AUTO.
CHECK REGISTRATION STATUS OF SIP USERS
After phones have had enough time to boot (allow about 2 ½ minutes), one location where
the status of SIP phones can be displayed is on the following screen:
13. Navigate to the Voice / Stations / User Accounts screen.
If SIP user has registered with the NetVanta 7100, a line displays below the word SIP.
If SIP user has not registered with the NetVanta 7100, a line displays though the word SIP.
The MAC address entered for this phone can also be seen by hovering cursor of
NetVanta 7100 Exercise – Basic Installation and Call Handling
NetVanta IP Telephony Course
Click Apply after
making change
?
bubble.
L2-9
