AUTO ATTENDANT CALL HANDLING
Inbound calls go to the Auto Attendant and then the calling party enters the extension of
the inside user. In the following steps, you will enable "debug voice summary" and view
the output while placing the calls.
You may want to read through the following steps before placing calls.
23. From the "Enable Mode" of the Command Line Interface, enter the debug voice
summary command. View output while placing call below.
IPT# debug voice summary
The symbol represents a call made from your own phone into the NetVanta IP
Telephony Course Auto Attendant.
24. Call your IPT lab site and enter 2004 when asked for extension.
1-256-665-9214
1. Dial
2. Enter Pass Code for Student Auto Attendant (your 4 digit passcode)
3. Press 1 to place call into your first Analog Trunk
Call is initiated inbound on the first Analog trunk to the Auto Attendant (8200)
4. Enter 2004 when asked for extension.
Call is sent to voice user 2004. Call coverage is configured to "Go to
Voicemail" after 4 rings.
5. Press '0' for operator as soon as call enters Voicemail. "DO NOT" leave
message.
Call is sent to the Operator Group. Since user 2003 is the only member of this
group, call goes to user 2003.
The Operator Group Call coverage is configured to "Go to Auto Attendant"
after 4 rings.
6. Hang-up phone after watching debug output of the call flow above.
