ADTRAN NetVanta 7100 Basic Installation And Call Handling page 8

NetVanta 7100 Exercise – Basic Installation and Call Handling
6. From the Voice / Stations / User Accounts screen, complete the steps below:
7. Enter SIP User #2's extension, name, and Phone Type.
8. Select the New Address option and then enter the MAC address of the
ADTRAN/Polycom SoundPoint IP 601.
9. Change the Phone Model to ADTRAN/Polycom SoundPoint IP 6xx and then click
Apply.
Q: What information must be entered to create a new SIP user for a known phone model?
____________________________________________________________________
Q: Where are phone configuration files created by the NetVanta 7100 stored?
____________________________________________________________________
L2-8 NetVanta IP Telephony Course
SIP User 2
Extension: 2004
First Name: Your
Last Name: Choice
Phone Type: SIP
Phone Model: SoundPoint IP 6xx
Select New Address
and then enter Phone
MAC Address of your
Polycom phone
