ADTRAN NetVanta 7100 Basic Installation And Call Handling page 7

CREATE SIP VOICE USERS 2003 and 2004
1. Select Voice / Stations / User Accounts from the NetVanta 7100 menus.
Phone config files
can only be created
for recognized
phone models.
2. Enter SIP User #1's extension, name, and Phone Type.
3. Select the New Address option and then enter the MAC address of the ADTRAN IP
712 phone.
4. Change the Phone Model to ADTRAN IP 712
5. Click Apply and Add Another User.
Clicking "Apply and Add Another User" creates the configured voice user but leaves you
on the Voice / Stations / User Accounts screen instead of the New Voice User Edit screen.
NetVanta 7100 Exercise – Basic Installation and Call Handling
NetVanta IP Telephony Course
SIP User 1
Extension: 2003
First Name: Your
Last Name: Choice
Phone Type: SIP
Phone Model: ADTRAN IP 712
Select New Address
and then enter Phone
MAC Address of your
ADTRAN phone
L2-7
