Firmadoor ® Series 2 Industrial Doors INSTALLATION INSTRUCTIONS DISCLAIMER THESE INSTRUCTIONS ARE INTENDED FOR PROFESSIONAL GARAGE DOOR INSTALLERS Note: All references are taken from inside looking out Part No. 00839. Revision 5 April 2011... -
Page 2: Table Of Contents
Firmadoor ® Series 2 Installation Instructions CONTENTS 1.0 BEFORE YOU START SAFETY CHECKLIST PREPARATION FASTENER RECOMMENDATIONS FOR FITTING GARAGE DOORS REQUIREMENTS BEFORE INSTALLATION 2.0 INSTALLATION FIXING REQUIREMENTS BRACKET FIXING POSITION DOOR ON BRACKETS INSTALL GUIDES SPRING TENSIONING BOTTOM RAIL STOPS LOCKING 3.0 AFTER INSTALLATION CARE Revision 5 April 2011... -
Page 3: Before You Start
Firmadoor ® Series 2 Installation Instructions 1.0 BEFORE YOU START 1.1 SAFETY CHECKLIST The following hazards and hazard controls have been identifi ed for installers during the installation of this door. Hazard Control • Housekeeping - risk of slip trip or fall •... -
Page 4: Fastener Recommendations For Fitting Garage Doors
Firmadoor ® Series 2 Installation Instructions 1.3 FASTENER RECOMMENDATIONS FOR FITTING GARAGE DOORS DIAMETER LENGTH OF FASTENER MATERIAL FASTENER TYPE(S) OR TYPE (See Note) 5/16” 1½” Coach Bolts (Hex Lag Screw) - combined with wall plugs 3/8” 2” 5/16” 50mm New Solid Brick Macplugs (wall plugs) to suit above 3/8”... -
Page 5: Requirements Before Installation
Firmadoor ® Series 2 Installation Instructions 1.4 REQUIREMENTS BEFORE INSTALLATION B&D Firmadoors are normally installed to operate behind the opening, overlapping as described in the dimension sketch, opposite. Openings should therefore have suffi cient return on both PLAN Curtain sides to accommodate the support brackets and door guides, with necessary working clearances. -
Page 6: Bracket Fixing
Firmadoor ® Series 2 Installation Instructions ALTERNATE METHODS OF ATTACHING BRACKETS AND GUIDES BRICK STEEL For Brackets: CONSTRUCTION CONSTRUCTION Use six 10mm (3/8”) bolt size masonry anchors; (dynabolts or similar). Right Hand For Guides: Bracket Use the 40mm x 8mm (1V x 5/16”) Masonry coach screws supplied, with a good Anchors... -
Page 7: Install Guides
Firmadoor ® Series 2 Installation Instructions For doors up to 3000mm high, rest axle on cast iron saddle. For doors over 3000mm high, rest axle between two cast iron Rest axle on cast iron saddle. Immediately loosely secure with saddles. Immediately loosely secure with “U” bolts, nuts and “U”... -
Page 8: Spring Tensioning Bottom Rail Stops
Firmadoor ® Series 2 Installation Instructions 2.5 SPRING TENSIONING BOTTOM RAIL STOPS Check top of guide lead in to ensure that the door does not make contact when rotated. Damage to nylon running strips could result. The curtain must feed in smoothly without bumping – adjust lead in as required. Apply, tension to the springs by rotating door approximately two (2) complete turns in a forward direction (see arrow on sketch A) after ensuring axle is securely clamped. - Page 9 Firmadoor ® Series 2 Installation Instructions METHOD OF FITTING OPTIONAL SELF ADHESIVE LOCK BAR RETAINERS PADBOLT TYPE LOCKING Position as indicated and clean the surface before proceeding. 1. Peel back and stick in position. Wave Washer 2. For additional strength drill 2 x holes from inside using Flat Washer retainer as a template.
-
Page 10: After Installation Care
Firmadoor ® Series 2 Installation Instructions 3.0 AFTER INSTALLATION CARE GENERAL CARE OF YOUR REGULAR MAINTENANCE REQUIRED FIRMADOOR SERIES 2 INDUSTRIAL DOOR B&D recommends that you check the operation of your B&D Firmadoor Series 2 Industrial Door at least every six months CLEANING (more regularly in extreme environments or frequent use).
