Summary of Contents for B&D PanelPro SDO-4V1 Tri-Tran+
- Page 1 PanelPro Sectional Door Opener SDO-4V1 Tri-Tran Home Owner’s Manual Doc #: 161014_00 Part #:79121 Released: 24/03/14 B&D Doors is a division of B&D Australia Pty Ltd ABN 25 010 473 971...
-
Page 2: Table Of Contents
PanelPro SDO-4V1 Home Owner’s Manual Table of Contents 1. Safety Rules 2. Features 3. Specifications 4. Operating your door 5. User Operating Controls 6. Opener Safety & Security 6.1 Manual Door Operation 6.2 Emergency Evacuations 6.3 Power Failure 6.4 Re-Engaging the Opener 6.5 Security - Inbuilt Locking Facility 7. -
Page 3: Safety Rules
PanelPro SDO-4V1 Home Owner’s Manual 1. Safety Rules Please read these important safety rules This automatic garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the following safety rules. Failure to comply with the following instructions may result in death, serious personal injury or property damage. -
Page 4: Features
PanelPro SDO-4V1 Home Owner’s Manual 2. Features Warranty Self Locking Two (2) year/5,000 cycles full parts and labour There is no need to manually lock your garage warranty on motor, electronics and mechanical door, as the opener ‘positively’ locks the door components of the opener when installed by an when closed. -
Page 5: Specifications
PanelPro SDO-4V1 Home Owner’s Manual 3. Specifications Technical Specifications Power supply 230V - 240Va.c. 50Hz Maximum door opening: Width: 4950mm (13.5m Height: 2440mm Weight: 100kg Minimum headroom 25mm Short Term Peak Force 650N (65kg) Rated force 400N (40kg) with Chain Nominal force 150N (15kg) Receiver type... -
Page 6: Operating Your Door
PanelPro SDO-4V1 Home Owner’s Manual 4. Operating your door For maximum efficiency of your opener, your garage door must be in good operating condition. An annual service of your garage door by an Approved Dealer is recommended. CAUTION: Activate the opener only when the door is in full view, free of obstructions and with the opener properly adjusted. -
Page 7: User Operating Controls
PanelPro SDO-4V1 Home Owner’s Manual 5. User Operating Controls Button (Fig 5.1) Function 1. OPERATE Opens/stops/closes the door 2. CODING LED (Red) Flashes when a code is being stored or when the transmitter button is pressed 3. DOOR CODE (Blue) Is used for storing or erasing transmitter buttons for door operation 4. -
Page 8: Opener Safety & Security
PanelPro SDO-4V1 Home Owner’s Manual 6. Opener Safety & Security 6.1 Manual Door Operation WARNING! When operating the To disengage the opener from the door (preferably manual release (while the door is with the door in the closed position), pull down open) the door may fall rapidly due on the string handle on an angle towards the door to weak or broken springs, or due to... -
Page 9: Safety Testing
PanelPro SDO-4V1 Home Owner’s Manual y 7. Safety Testing 7.1 Test the Close Cycle CAUTION: Take care when a. Press the transmitter to open the door. (Fig 7.1) completing a safety test. Failure b. Place a piece of timber approximately 40mm high on to follow this warning can result (Fig 7.2). -
Page 10: Coding Transmitters
PanelPro SDO-4V1 Home Owner’s Manual 8. Coding Transmitters 8.1 Storing the Transmitter Code ELECTROCUTION! The button The opener can only operate from transmitters that have cover is the only cover that should been programmed into its receiver. The receiver needs to be removed. -
Page 11: Enabling Aux Output
PanelPro SDO-4V1 Home Owner’s Manual 8. Coding Transmitters 8.4 Enabling AUX Output Press the DOOR CODE button four (4) times - the DOOR CODE LED will illuminate and the courtesy (Fig 8.2) light will flash quickly. Press one of the four (4) buttons on the transmitter for two (2) seconds, the DOOR CODE LED will begin to flash, pause for two (2) seconds, then Press DOOR... -
Page 12: Troubleshooting Guide
PanelPro SDO-4V1 Home Owner’s Manual 9. Troubleshooting Guide Symptom Possible cause Remedy The door stops or moves Garage door in poor condition e.g. Check the door’s operation - see very slowly springs may be broken monthly maintenance (Section 10.1) The opener does The opener does not have power Plug a device of similar voltage not work from the... - Page 13 PanelPro SDO-4V1 Home Owner’s Manual 9. Troubleshooting Guide Symptom Possible cause Remedy Courtesy Light flashes The opener has reached Contact your dealer and arrange and the opener beeps the number of cycles a door service. Alternatively press 5 times after each recommended before servicing.
-
Page 14: Maintenance
PanelPro SDO-4V1 Home Owner’s Manual 10. Door Maintenance 10.1 Door Maintenance WARNING! Failure to maintain your Whilst your opener does not require any periodic garage door may void the warranty maintenance, the door that it is fitted to, does. Your on your garage door opener. -
Page 15: Opener Maintenance
PanelPro SDO-4V1 Home Owner’s Manual 10. Opener Maintenance 10.4 Opener Maintenance To ensure a long and trouble free life for your opener the following is recommended: • Monthy: Run the Safety Testing procedures in Section 7 to ensure garage door is fit for use. NOTE: If the door does not operate smoothly, call your nearest dealer. -
Page 16: Warranty
PanelPro SDO-4V1 Home Owner’s Manual 11. Warranty Product: PanelPro SD0-4V1 Tri-Tran Purchased from:______________________________Purchaser:___________________________________ (described as “you” below) Address:_____________________________________Installed by:__________________________________ Installed on (date):____________________________Invoice No:__________________________________ 1. MAKING A CLAIM - To make a warranty claim you must: a. produce a copy of the receipt of purchase, together with this warranty certificate with the above details completed; and b. - Page 17 PanelPro SDO-4V1 Home Owner’s Manual 11. Warranty 5. WHAT VOIDS THE WARRANTY - Subject to paragraph 6, this warranty does not extend to, and B&D will be relieved of, all obligations, responsibilities and liabilities in the event that defects in the Product are directly or indirectly, in the opinion of B&D, due to or resulting from: a.
-
Page 18: Optional Accessories
PanelPro SDO-4V1 Home Owner’s Manual 12. Optional Accessories There are a range of additional accessories for your added convenience and security. Contact your dealer for installation of these accessory items. Safety Beams • - Provides additional protection if the door is closing onto your property or person. -
Page 19: Service Schedule
PanelPro SDO-4V1 Home Owner’s Manual 13. Service Schedule Year / Date Details Approx. Cycles 1 / 3,000 2 / 6,000 3 / 9,000 4 / 12,000 5 / 15,000 B&D Doors is a division of B&D Australia Pty Ltd Phone: 13 62 63 Website: www.bnd.com.au Diamond PD Power Drive : Instruction ©... - Page 20 Is your opener beeping and flashing? It may be time for a service (for more details see section 10.5) For a service contact your dealer using the details below... Dealer: B&D Doors is a division of B&D Australia Pty Ltd ABN 25 010 473 971...
