B&D EasyLifter Installation Instructions Manual

B&D EasyLifter Installation Instructions Manual

Rolling garage door opener
Hide thumbs Also See for EasyLifter:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Easylifter
™
ROLLING GARAGE DOOR OPENER
Warning: It is vital for the safety of persons to
OWNERS COPY
follow all instructions. Failure to comply with the
installation instructions and the safety warnings
may result in serious personal injury and/or

Installation Instructions

property and remote control opener damage.
Please save these instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyLifter and is the answer not in the manual?

Questions and answers

Related Manuals for B&D EasyLifter

Summary of Contents for B&D EasyLifter

  • Page 1: Installation Instructions

    Easylifter ™ ROLLING GARAGE DOOR OPENER Warning: It is vital for the safety of persons to OWNERS COPY follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in serious personal injury and/or Installation Instructions property and remote control opener damage.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Warning - It is vital for the safety of persons to follow all instructions. Failure to comply with the following Safety Rules may result in serious personal injury and/or property damage. ADDITIONAL SAFETY protection The unit should be installed so that it is protected from STRONGLY recommend the fitting of a Photo Electric the elements.

  • Page 4: Manual Operation

    FEATURES OPEN AND CLOSE DRIVE SECURITY CODE STORE Your Easylifter Auomatic Rolling Garage BUTTONS The Easylifter Garage Door Opener Door Opener has many features which Developed by B&D to aid with the uses state of the art technology in you will appreciate. The components...

  • Page 5: Operating Controls

    OPERATING CONTROLS 1. LIGHT CODE button (White) is 7. O/S/C button (Yellow) is used 15. P.E. INPUT is for connection of used for storing or erasing the during installation to test the Open, Stop Photo Electric Beams (optional extra) transmitter button (code) you wish to and Close cycles for the Opener.
  • Page 6 OPERATING CONTROLS LIGHT CODE BUTTON (WHITE) OPEN DRIVE BUTTON (GREEN) DOOR CODE BUTTON (BLUE) OPEN LIMIT (RED) CLOSE DRIVE BUTTON (RED) CLOSE LIMIT CAM (RED) CLOSE LIMIT LED (RED) FORCE MARGIN SET BUTTON AUTO CLOSE BUTTON (WHITE) P.E. INPUT RESET BUTTON EXTERNAL RECEIVER INPUT O/S/C BUTTON (YELLOW) O/S/C INPUT...

  • Page 7: Package Contents

    PACKAGE CONTENTS ITEM QUANTITY EASYLIFTER DRIVE UNIT HAND HELD TRANSMITTER ALKALINE BATTERY A23 12V WEIGHT BARS (NOT INCLUDED IN SOME MODELS) SCREW M5x40mm (NOT INCLUDED IN SOME MODELS) HEX NUT M5 (NOT INCLUDED IN SOME MODELS) SPRING WASHER I.D 5 (NOT INCLUDED IN SOME MODELS) SCREW #6x1”...

  • Page 8: Before Installation

    3. LEFT OR RIGHT HAND INSTALLATION The Easylifter Automatic Garage Door Opener can be installed on the left or right hand side of the door (when looking out from the inside of the garage). If the opener is to be installed on...

  • Page 9: Mounting The Opener

    MOUNTING THE OPENER 4. FIXING DRIVE UNIT TO THE DOOR CHECK IF “U” The Easylifter Drive Assembly can be fixed to the rolling BOLT IS TIGHT garage door in a variety of ways. Described below is one method of fixing. Make sure there is enough side room (135mm from the end of the door shaft to the wall) to slide the drive unit onto the shaft.

  • Page 10: Setting Limits

    SETTING LIMITS 5. FIXING OF DOOR CURTAIN TO DRUM FIG. 13 WHEEL The door curtain has to be secured to the drum wheel with DRUM WHEEL suitable fasteners. 1. With the door in the fully closed position, mark the curtain (Fig.
  • Page 11 SETTING LIMITS NOTE: If the door has not reached the desired limit position by FIG. 16 more then 30mm, then it is recommended that the green limits cam be adjusted again before the green ne adjustment screw is adjusted. CLOSE LIMIT ADJUSTMENT Press in and hold the red Close button .
  • Page 12 SETTING LIMITS OPEN LIMIT ADJUSTMENT FIG. 18 Press and hold the green Open button (Fig. 18). The door should start opening. Release the Open button when the door reaches the desired open limit stop position. If the green LED (Fig. 18) is illuminated and the desired limit stop position has been reached then the limit adjustment is complete.

  • Page 13: Setting Safety Obstruction Force

    FIG. 20 OBSTRUCTION FORCE The Safety Obstruction Force is calculated automatically and set in memory on the Easylifter. This applies to both the Open Force and Close Force. Warning: When step 7.1 is initiated the garage door will do a full open and close cycle automatically.

  • Page 14: Coding Transmitters

    8.1 STORING TRANSMITTER CODE 1. Press the DOOR CODE button on the Easylifter opener. The Door Code LED will illuminate to indicate that learn mode is activated. If a valid code is not stored in 15 seconds the Easylifter opener will exit learn mode.
  • Page 15 CODING TRANSMITTERS 11. SETTING THE TRANSMITTER TO OPERATE THE FIG. 25 COURTESY LIGHT Although the courtesy light comes on with each operation of the opener, the courtesy light may also be controlled by a remote control transmitter without operating the door. To code one of the remote control transmitter buttons to turn the courtesy light on and off: 1 - Press the Light Code button on the opener.

  • Page 16: Factory Default Settings

    PE BEAM AND AUTO CLOSE 14. FITTING THE SAFETY PHOTO FIG. 28 ELECTRIC BEAM SENSOR (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage.

  • Page 17: Door Status Indicators

    PARAMETERS & SPECIFICATIONS DOOR STATUS INDICATORS OPEN LED CLOSE LED DOOR STATUS DOOR OPENER STATE BEEPER GREEN LED YELLOW OPEN CLOSE FLASHING OPENING FLASHING CLOSING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN OPENING FLASHING BEEPS WHILE DOOR OBSTRUCTED WHEN CLOSING FLASHING DOOR IS MOVING ALTERNATING...

  • Page 18: Troubleshooting

    TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged.

  • Page 19: Spare Parts List

    SPARE PARTS LIST...

  • Page 21: Warranty

    Australia Pty Ltd. ‘Purchaser’ means the purchaser of the Opener. ‘Opener’ means the ‘Easylifter Automatic Garage Door Opener’ ‘Authorised Distributor’ means an approved B&D distributor of the Opener. ‘Major Components’ means all components of the Opener that make up the power head that is attached to a garage door.
  • Page 22 WARRANTY Subject to paragraph 12 hereof; the obligations of B&D under this warranty are limited to those contained herein and such warranties are expressly in lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage in the trade to the contrary.
  • Page 24 QLD Office: 17 Oasis Court, Clontarf 4019. Ph: (07) 3883 0200 NSW Office: 34-36 Marigold St, Revesby 2212. Ph: (02) 9722 5555 VIC/TAS Office: 147-153 Canterbury Road, Kilsyth 3137. Ph: (03) 9237 7766 SA Office: 23 Frederick Road, Royal Park 5014. Ph: (08) 8440 4747 WA Office: 96 Mulgul Drive, Malaga 6090.
