- Page 1 ® Controll-A-Door Diamond PD & Roll-A-Pro Rolling Door Opener Tri-Tran+ Home Owner’s Manual Doc #: 161018_00 Part #:79127 Released: 30/07/2014 B&D Doors is a division of B&D Australia Pty Ltd ABN 25 010 473 971...
-
Page 2: Table Of Contents
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual Table of Contents 1. Safety Rules 2. Features 3. Specifications 4. Operating your door 5. User Operating Controls 6. Opener Safety & Security 6.1 Manual Door Operation 6.2 Emergency Evacuations 6.3 Power Failure 6.4 Re-Engaging the Opener 6.5 Security - Inbuilt Locking Facility 7. -
Page 3: Safety Rules
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 1. Safety Rules Please read these important safety rules This automatic garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the following safety rules. Failure to comply with the following instructions may result in death, serious personal injury or property damage. -
Page 4: Features
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 2. Features Warranty Service Fault Indicator CAD Diamond PD - Five (5) year/ 20,000 cycles Flashing LEDs on the control panel easily identify Roll-A-Pro - Two (2) year/ 5,000 cycles operational problems or service requirements. Safety Beam Failure Emergency Close Full parts and labour warranty on motor, electronics and mechanical components of... -
Page 5: Specifications
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 3. Specifications Technical Specifications Controll-A-Door Roll-A-Pro ® Diamond PD Power supply 230V - 240Va.c. 50Hz 230V - 240Va.c. 50Hz Maximum door opening Door Height: 3.25 turns of the drum wheel 3.25 turns of the drum wheel (approx. -
Page 6: Operating Your Door
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 4. Operating your door For maximum efficiency of your opener, your garage door must be in good operating condition. An annual service of your garage door by a Dealer is recommended. CAUTION: Activate the opener only when the door is in full view, free of obstructions and with the opener... -
Page 7: User Operating Controls
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 5. User Operating Controls Button (Fig 5.1) Function 1. OPERATE Opens/stops/closes the door. 2. CODE SET LED (Red) Flashes when a code is being stored or when the transmitter button is pressed 3. -
Page 8: Opener Safety & Security
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 6. Opener Safety & Security 6.1 Manual Door Operation WARNING! When operating the To disengage the opener from the door (preferably manual release (while the door is with the door in the closed position), pull down on open) the door may fall rapidly due the string handle (Fig... -
Page 9: Safety Testing
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 7. Safety Testing 7.1 Test the Close Cycle CAUTION: Take care when a. Press the transmitter to open the door. (Fig 7.1) completing a safety test. Failure b. Place a piece of timber approximately 40mm high to follow this warning can result (Fig 7.2). -
Page 10: Coding Transmitters
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 8. Coding Transmitters 8.1 Storing the Transmitter Code ELECTROCUTION! The button The opener can only operate from transmitters that cover is the only cover that should have been programmed into its receiver. The receiver be removed. -
Page 11: Setting The Vacation Mode
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 8. Coding Transmitters 8.4 Enabling AUX Output Press the CODE SET button four (4) times - the CODE SET LED will illuminate and the courtesy light will flash quickly. Press one of the four (4) buttons on the transmitter for two (2) seconds, the CODE SET LED will begin to flash, pause for two (2) seconds, then press the same button again for two (2) seconds. -
Page 12: Troubleshooting Guide
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 9. Troubleshooting Guide Symptom Possible cause Remedy The opener does The opener does not have power Plug a device of similar voltage not work from the (e.g. a hairdryer) into the power transmitter point and check that it is OK Replace the battery (Section 10.5) - Page 13 ® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 9. Troubleshooting Guide Symptom Possible cause Remedy The SERVICE LED has A Fault has been detected. The Record opener function in (Fig 9.1) started to flash and is fault will be active each time an then press the LIMIT SET button beeping numerous times attempt is made to operate the...
-
Page 14: Door Maintenance
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 10. Door Maintenance 10.1 Door Maintenance WARNING! Failure to maintain your Whilst your opener does not require any periodic garage door may void the warranty maintenance, the door that it is fitted to, does. on your garage door opener. -
Page 15: Opener Maintenance
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 10. Opener Maintenance 10.4 Opener Maintenance To ensure a long and trouble free life for your opener the following is recommended: • Monthy: Run the Safety Testing procedures in Section 7 to ensure garage door is fit for use. NOTE: If the door does not operate smoothly, call your nearest Approved Dealer. -
Page 16: Warranty
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 11. Warranty Product: CAD Diamond PD and Roll-A-Pro Purchased from:______________________________Purchaser:___________________________________ (described as “you” below) Address:_____________________________________Installed by:__________________________________ Installed on (date):____________________________Invoice No:__________________________________ 1. MAKING A CLAIM - To make a warranty claim you must: a. - Page 17 ® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 11. Warranty 5. WHAT VOIDS THE WARRANTY - Subject to paragraph 6, this warranty does not extend to, and B&D will be relieved of, all obligations, responsibilities and liabilities in the event that defects in the Product are directly or indirectly, in the opinion of B&D, due to or resulting from: a.
-
Page 18: Optional Accessories
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 12. Optional Accessories There are a range of additional accessories for your added convenience and security. Contact your Dealer for installation of these accessory items. Safety Beams • - Provides additional protection if the door is closing onto your property or person. -
Page 19: Service Schedule
® Controll-A-Door Diamond PD & Roll-A-Pro Home Owner’s Manual 13. Service Schedule Year / Date Details Approx. Cycles 1 / 3,000 2 / 6,000 3 / 9,000 4 / 12,000 5 / 15,000 B&D Doors is a division of B&D Australia Pty Ltd Phone: 13 62 63 Website: www.bnd.com.au Diamond PD Power Drive : Instruction... - Page 20 ® Controll-A-Door P Diamond SDO-2 Home Owner’s Manual Is your sticking and hard to operate? It may be time for a service (for more details see section 10) For a service contact your dealer using the details below... Dealer: B&D Doors is a division of B&D Australia Pty Ltd ABN 25 010 473 971...
