2. Function Menu
AUTO Confi gure – Used for PC signals to auto fi t image to screen.
DPMS – When selected to ON, the Digital Power Management System will place the monitor into standby when there is no
input signal for 12 seconds and will automatically turn on the monitor when a signal is applied to the last selected source.
Reset – Restores the monitor to factory settings
OSD TIME-OUT – Set time in seconds (0 to 60) for OSD to drop from screen after last button push
SLEEP TIMER – Used to automatically turn monitor off after programmed delay
Language – Not Used
3. TV SETUP MENU
AUTO Search – Will scan through all channels to fi nd available signals and automatically program the tuner.
Manual Search – Use to scan individual channels to add or eliminate channels of the tuner
Auto Fine Tune – Set to ON for automatic adjustment of each channel to achieve the strongest signal.
Set to OFF to enable manual adjustment of the TV tuner.
Fine Tune – When AUTO FINE TUNE is off, this function will be enabled for manual adjustment of the TV tuner
TV Source – Select between off air signals (Channels 2-69) or RF Cable system (Channel 1-125)
4. Screen Menu
V-Position – Use LEFT and RIGHT buttons to adjust horizontal position of the PC Image
H-Position – Use LEFT and RIGHT buttons to adjust wertical position of the PC Image
Frequency – Use LEFT and RIGHT buttons to adjust the pixel clock width of the PC Image
4
(Use UP/DOWN/LEFT/RIGHT buttons to select function)
(Use UP/DOWN/LEFT/RIGHT buttons to select function)
(Use UP/ DOWN/ LEFT/ RIGHT buttons to select function)
Auto Confi gure
DPMS
Reset
OSD Time Out
Sleep Timer
Language
Auto Search
Manual Search
Auto Fine Tune
Fine Tune
TV Source
Fine Tune Menu
H-Position
V-Position
Frequency
V-R151P Users Guide
V-R151P Users Guide
TV
S-Video
Video
PC
TV
S-Video
Video
PC
TV
S-Video
Video
PC
