Standard Accessories
11
Accessories Supplied with the V-R151P-4A
• Users manual
• "Brick" type 12vdc power supply with 4 Pin Female XLR connector
• "V" Mount battery adapter
• VESA 75 Mount
Optional Accessories
12
Desk Stand - VP-LCD171H-ST-01 - Use for Desk Top
Warranty
13
Marshall Electronics warranties to the first consumer, that this V-R151P-4A 15 inch LCD rack mounted monitor will, under normal use, be free from defects in workmanship and materials, when
received in its original container, for a period of one year from the purchase date.
This warranty is extended to the purchasing end user only and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, Marshall
Electronics reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to you.
This warranty does not apply to product exterior and cosmetics. Misuse, abnormal service or handling, improper alterations or modifications in design or construction, voids this warranty. No
sales personnel of the seller, nor any other person is authorized to make any warranties other than those described above, or to extend the duration of any warranties on behalf of Marshall
Electronics, beyond the time period described above.
An extra note about LCD displays: It is considered normal for a minimal amount of pixels, not to exceed three, to fail on the periphery of the display active viewing area. Marshall Electronics
has the option to reserve service for display pixel failure if deemed unobtrusive to effective use of the monitor by our technicians.
Due to constant effort to improve products and product features, specifications may change without notice.
Marshall Electronics
1910 East Maple Ave.
El Segundo, CA 90245
Tel.: 800-800-6608 • 310-333-0606
Fax: 310-333-0688
www.LCDRacks.com
Email: sales@lcdracks.com
V-R151P-4A Users Guide
V-R151P-4A
Users Guide
Product Overview
Features
Specifications
Connectors
Front Panel Indicators and Controls
Menu Functions
PC Formats Supported from VGA and DVI Connectors
Video Formats Supported By Component and DVI Inputs
Video Formats Supported By Composite and S-Video Inputs
Standard Accessories
Optional Accessories
Warranty
1
2
3
Setup
4
5
6
7
8
9
10
11
12
13
