Marshall Electronics V-R151P Specifications

18 LCD Racks
15" Rack Mountable LCD Monitor with Built-in 125ch TV
V-R151P
Tuner, Tally Light and Audio. Only 6 Rackspaces High
Display (Viewing area)
15.1" (11.69" x 9.12")
Resolution (Pixels) 1024 H x RGB x 768 V
Dot Pitch 0.297 mm x 0.302 mm
Brightness (in cd/m²) 250 cd/m²
System
NTSC/PAL config. switch
Inputs per panel (total) Video: 1 S-Video, 1 Composite, 1 XGA, 1 RF(TV) (NTSC only).
Audio: 2 Unbalanced RCA, 1 RF Stereo pair (TV)
Dimensions 19.12"W x 10.5"H x 2.25"D
Approx. Weight
9.5 lbs
Power Consumption 12 VDC, 2.0 Amps
The V-R151P is a 15" LCD rack mounted unit 6U high with a 125 channel TV Tuner and Audio. This
panel has 1024 x 768 pixels producing a true high resolution image. The built-in audio system has
a stereo input that is mono compatible. For added flexibility, this unit has a green tally light and can
accommodate NTSC/PAL composite video, TV, S-Video or XGA for computer monitoring. All V-R Series
models are constructed of steel and aluminum, and can be tilted 90 degrees while rackmounted. Unit
includes power supply and owners manual.
·
High Resolution LCD panel, 1024 x 768 pixels, 786,432 total
·
Bright 250 cd/m² candle luminance
·
Compact design fits in EIA standard rack 6U high
·
Built-in Speakers
·
Built-in 125 Channel TV Tuner (NTSC only)
·
Self-powered tally system
·
NTSC/PAL configuration switch
·
Unique 180 degree tilt adjustment while mounted in rack
6U
2.25"
Price: $2199.00
V-R171P
Inputs
Display (Viewing area)
Composite
Resolution (Pixels)
S-Video
Dot Pitch
180°
Brightness (in cd/m²)
XGA
System
RF
Inputs per panel (total)
Audio Unique 180° Tilt Mechanism
Dimensions
Approx. Weight
Power Consumption
The V-R171P is a 17" high resolution (1280 x 1024) LCD panel capable of producing nearly 17 million
colors. It accepts 1 composite video signal in either NTSC or PAL format. It also has an S-Video and
an SXGA inputs for computer monitoring. On-screen menu parameters are available for input selection,
16:9 or 4:3 aspect ratio, color, tint, contrast and brightness adjustments. All V-R Series models are
constructed of steel and aluminum, and can be tilted 90 degrees while rackmounted. The unit includes
power supply and owners manual.
·
High Resolution LCD panel, 1280 x 1024 pixels, 1,310,720 total
·
Unique Ultra Wide Viewing Angle LCD Panel, 170° in any direction
·
Bright 250 cd/m² candle luminance
·
Automatic NTSC/PAL signal recognition
·
Software driven 16:9 to 4:3 ratio switch
·
HDTV ready, will accept 1080i/720p signal with optional HD to VGA converter
·
Compact design fits in 19-inch EIA standard rack 8U high
·
Unique 180 degree tilt adjustment while mounted in rack
M a r s h a l l E l e c t r o n i c s
2.5"
17" Rack Mountable LCD Monitor only 8 Rack Spaces high
Inputs
17" (13.30" x 10.64")
Composite
1280 H x RGB x 1024 V
S-Video
0.264 mm x 0.264 mm
250 cd/m²
SXGA
NTSC/PAL auto rec
1 S-Video, 1 Composite, 1 SXGA
19.12"W x 13.80"H x 2.5"D
12. 5 lbs
12 VDC, 2.0 Amps
8U
Price: $2995.00
180°
Ultra-wide Viewing Angle Unique 180° Tilt Mechanism
