Assembly and Operating Instructions for
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
4 Burner Hooded Gas Barbecue
PALERMO
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PALERMO and is the answer not in the manual?

Questions and answers

Related Manuals for gascraft PALERMO

Summary of Contents for gascraft PALERMO

  • Page 1 Assembly and Operating Instructions for 4 Burner Hooded Gas Barbecue PALERMO Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    1. Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. CODE PART PALERMO Hood (Pre-Assembled to Body) HOOD Hood Handle Warming Rack...

  • Page 3: Parts Diagram

    2. Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 3. Hardware Reference Diagram Specifications subject to change without prior notice. Code Description Illustration Code Description Illustration ST4.0x10 M6x70 Screw Bolt M5x10 Ø6 Washer Bolt M5 Nut M6 Nut M6x15 Locknut Bolt M6x65 Bolt...
  • Page 5 4. Assembly IMPORTANT! • TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric spanner set. • The assembly of this barbecue requires 2 people. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
  • Page 6 Remove all loose components from the Barbecue Body (B1). Carefully lay the barbecue body on its back and also lay the assembled trolley on its back. CAUTION! Care must be taken to ensure the hood or lid does not fall open unexpectedly or becomes damaged when it is set on the ground.
  • Page 7 Carefully lay the Flame Tamers (B6) into the barbecue body ensuring it lies level within the body. Lay the Grills (B7) and Griddle (B8) into place. Ensure the cooking grill lies directly over the flame tamer on the LEFT side of the barbecue body. Install the Leg Support (C7) onto left legs using ST4.0x10 Screws (D1).
  • Page 8 The Drip Tray Brackets (B10, B11) are fixed tightly to the side panel of barbecue body with drip tray bracket bolts. Unscrew the bolts to move the brackets down and remove the Drip Tray (B12). Retighten the bolts, reverse drip tray and slide it back into position underneath the barbecue body.
  • Page 9 Attach the Warming Rack (A3) to the Hood (A1) and Barbecue Body (B1) as shown. Make sure that the swing legs fix to the body of the barbecue and the shorter fixed legs go through the holes in the hood. Insert the Cylinder Hook (B13) into the hole provided in the left side of the barbecue body.

  • Page 10: Leak Testing

    Connect the Hose and Regulator Assembly (B5) to the barbecue. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the connection. The nut must be tightened with the use of a spanner.

  • Page 11: Gas, Regulator And Hose

    surface. 5. Important Information Before you use your barbecue, perform a leak test. This is the only safe and sure way Please read these instructions carefully to detect any gas leaking from joints and before assembly and use of your barbecue. connections of the barbecue after assembly.

  • Page 12: Installation

    8.2. Preparation Before Cooking 7. Installation To prevent foods from sticking to the cooking surface, please use a long handled brush to 7.1. Selecting a Location apply a light coat of cooking or vegetable oil This barbecue is for outdoor use only and before each barbecuing session.
  • Page 13 • bake or roast on a metal baking tray and set it Insert lit match through the right match- on one side of the cooking grill. lighting hole on the right side of the barbecue body and place near rightmost Turn the burner directly under the food to the burner porthole.

  • Page 14: Care And Maintenance

    given below. cleaning. Do not leave the barbecue exposed to outside weather conditions or stored in 8.10. Fat Fires damp, moist areas. Empty and clean the drip tray (and foil liner, if applicable) of food debris after each cooking Never handle hot parts with unprotected session.

  • Page 15: Technical Specifications

    SM-H5400 not a fault in the barbecue and is therefore not covered by the terms of the warranty. If Gas Consumption: Palermo: 1156g/hr required, the tray can be washed in hot soapy water. Specifications subject to change without prior notice.

  • Page 16: Troubleshooting

    11. Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas Clean jets and gas hose hose Electrode or ignition button wire is...
