gascraft SERRANA Manual

6 burner bbq with side burner
Hide thumbs
Table of Contents

Advertisement

Quick Links

SERRANA
6 BURNER BBQ
WITH SIDE
BURNER
Photographs are not to scale.
Specifications subject to
change without prior notice.
IMPORTANT: Assembler/Installer
IMPORTANT!
be given to the final user of this BBQ. They contain important
ASSEMBLER: These instructions must be left with the user of the BBQ
for their reference. They contain important safety information required
instructions and warnings for continued safe use of the BBQ.
for continued safe use of the BBQ.
- these instructions must
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SERRANA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for gascraft SERRANA

Summary of Contents for gascraft SERRANA

  • Page 1 SERRANA 6 BURNER BBQ WITH SIDE BURNER Photographs are not to scale. Specifications subject to change without prior notice. 0359 IMPORTANT: Assembler/Installer - these instructions must IMPORTANT! be given to the final user of this BBQ. They contain important ASSEMBLER: These instructions must be left with the user of the BBQ for their reference.

  • Page 2: General Information

    GENERAL INFORMATION If you are unable to correct the leak by tightening the connections, turn off the gas and contact the supplier immediately. Gas Installation Code Always ensure the barbecue is kept away from flammable materials and the gas cylinder clear of any heat source. This BBQ is to be used with LPG only.

  • Page 3: Protect Children

    GENERAL INFORMATION Location of your Barbecue DO NOT use your barbecue in garages, porches, sheds, breezeways, or other enclosed areas. Your barbecue is to be Ensure the barbecue is set up on a level and stable used OUTDOORS. The barbecue is not intended to be surface.
  • Page 5 Description Description Figure Figure Hood Bottom Tray Right Door Barbecue tray Warming Rack Door Handle Left Door Side Table Flame Tamer oor Axle Cart Bracket Lock Catser Body Magnet Back Right Leg Front Left Leg Front Right Leg Back Left Leg Side Panel Gas Tank Holder Grease Tray...
  • Page 6 Description Figure Cooking Grid Screw (M6X10) Clip Screw (M4X10) Screw (M3X10) Nut (M3) Nut (M6)
  • Page 7 ASSEMBLY INSTRUCTIONS Step 1 Back Left Back Right Front Right Front Let 8Pcs M6X10 Step 2 4Pcs M6X10...
  • Page 8 Step 3 Step 4 4Pcs M6X10 2Pcs M3X10 (M3) 2Pcs...
  • Page 9 Step 5 4Pcs M6X10 Step 6 4Pcs M6X10...
  • Page 10 Step 7 Step 8 8Pcs M6X10...
  • Page 11 Step 9 8Pcs M6X10 Step 10 4Pcs M6X10...
  • Page 12 Step 11 4Pcs M6X10 Step 12 2Pcs M4X10...
  • Page 13 Step 13 2Pcs M4X10 Step 14 2Pcs M4X10...
  • Page 14 Step 15 Insert side burner rack (27). Attach cylinder hook (32) using 2X(A)M6X10+(F)M6X2. Place flamer tamers (5) over burners under cast iron grills. Attach warming rack (3) securing with 2Xclip. Place 2XCast iron grills(31) and plate (2) in BBQ. 2Pcs M6X10 Clip 2Pcs...
  • Page 15 AAA 1.5v battery (not included), required to operate the side burner ignition 1.Unscrew the ignitor cap and remove 2.Install the "AAA" battery as shown and reinstall cap.

  • Page 16: To Check For Leaks

    BEFORE USE CHECK FOR LEAKS After the connection is made between hose assembly and BBQ valve, a leak test must be performed before the BBQ can be operated to check the connections are gas-tight. Never check for leaks with a naked flame, always use a soapy water solution TO CHECK FOR LEAKS Make 1 cup of leak detecting solution by mixing one part washing up liquid with 3 parts water.

  • Page 17: General Assembly

    GENERAL ASSEMBLY 7. Leak test the connection using a soapy water solution. Ensure no bubbles appear before proceeding. 8. Slowly open the gas cylinder valve all the way. Do not Connecting & Disconnecting to Gas Source put excessive force on the valve at the full open IMPORTANT: Before connecting and position, to avoid damaging the valve.
  • Page 18 steps. If the BBQ still fails to light, please refer to Grill Cooking the Manual Lighting Instructions The burners heat up the flame tamers underneath Confirm each burner is alight before attempting to the grill, which in turn heat the food on the grill. light another burner.

  • Page 19: Care And Maintenance

    Care and Maintenance Flare-Up Control *Very Important Notice* Flare-ups occur when meat is barbecued, and its Regularly clean your barbecue between uses and fat and juices fall upon the hot flame tamer. especially after extended periods of storage. Smoke of course helps give food its barbecued Ensure the barbecue and its components are flavour, but it is best to avoid excessive flare-up to sufficiently cool before cleaning.

  • Page 20: Barbecue Body

    When refitting the burners, be careful to check that the neck of the burner fits over the valve VERY IMPORTANT INFORMATION outlet. It is quite normal for surface rust to be present on CARE AND PROTECTION OF STAINLESS the burners. If rust appears between uses or in storage, clean with a soft brass wire brush.

  • Page 21: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using the LPG gas bottle is empty Replace with full bottle ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets Clean jets and gas hose or gas hose Electrode or igniton button wire Reconnect wire...
