Assembly and Operating Instructions for
4 and 6 Burner Hooded BBQ with Side Burner
TALCA-MH4451
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
•
THIS BBQ MUST NEVER BE LEFT UNATTENDED WHEN LIT AND IN USE.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
MANTA-MH5651
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TALCA-MH4451 and is the answer not in the manual?

Questions and answers

Related Manuals for gascraft TALCA-MH4451

Summary of Contents for gascraft TALCA-MH4451

  • Page 1 Assembly and Operating Instructions for 4 and 6 Burner Hooded BBQ with Side Burner TALCA-MH4451 MANTA-MH5651 Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    1. Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Gascraft Talca- Gascraft Manta- CODE PART MH4451 MH5651 Hood (Pre-Assembled to Body)

  • Page 3: Parts Diagram

    2. Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 3. Hardware Reference Diagram Specifications subject to change without prior notice. Code Description Illustration ST4.0x10 Screw White nickel plated ST4.0x10 Screw Black nickel plated M4 Nut M4x10 Bolt M6x40 Bolt M6x15 Bolt M6 Nut...
  • Page 5 4. Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 6 Unscrew the Locknut (D8x2pcs) from both ends of the Axle (C18). Insert the axle through the corresponding holes in the left legs, then slide one Wheel (C17) over each end of the axle. Secure the wheels into place with the locknuts. Carefully turn the assembled cabinet right side up.
  • Page 7 Rear View Attach the Upper Support (C15) between the front legs using M6x15 Bolts (D6x4pcs). Attach the Magnets (C16) onto the Upper support and Bottom panel using M4x10 Bolts (D4x4pcs) and M4 Nuts (D3x4pcs). Attach the Cylinder Pad (C10) to the left side panel using a M6x15 Bolt (D6) and a M6 Nut (D7).
  • Page 8 Fit the Left door (C13) and Right door (C14) to the cabinet by depressing the spring pins and placing into the cabinet, as shown. Rear Side Front Side Rear View Attach Drip tray left bracket (B10) to the right legs using ST4.0x10 Screws (D2x2pcs) as shown. Repeat above process for Drip tray right bracket (B11).
  • Page 9 Press the knobs(B6)onto valve stems as shown. Body Body supports supports Carefully place the Barbecue Body (B1) onto the body supports and fix using M6x15 Bolts (D6x4pcs) as shown. WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN PROPERLY SEATED.
  • Page 10 Note: 6 burner users skip this step and proceed directly to step 12. Remove Side Burner Grid (C5) from the Side burner shelf. Attach Side Burner Shelf Panel (C2) onto the Side Burner Shelf (C1) using M6x15 Bolts (D6x2pcs) and M6 Nuts (D7x2pcs).
  • Page 11 Attach the side valve to the side burner shelf using M4x10 Bolts (D4x2pcs). Press the Side Burner Knob (C6) onto the side burner valve stem. Attach the side shelf assembly to the barbecue body using ST4.0x10 Screws (D1x1pcs) and M6x15 Bolts (D6x4pcs) as shown.
  • Page 12 Insert the Cylinder Hook (B13) into the hole provided in the left side of the barbecue body. Attach the Drip Deflector (C9) under the side burner shelf using a M4x10 Bolt (D4) as shown.
  • Page 13 Insert the Drip Tray (B12) by sliding it underneath the barbecue body. Carefully lay the Flame tamers (B7) into the barbecue body ensuring it lies level within the body. Lay the Grill (B8) and Plate (B9) into place. NOTE: Ensure that the flame tamers lie directly underneath grill in the left of barbecue body. NOTE: The Manta 6 burner BBQ is supplied with 3pcs flame tamer.
  • Page 14 Place Side Burner Grid (C5) into the Side burner shelf. Note: Only use cookware with a base diameter of 150-220mm on the side burner. Attach the Warming Rack (A4) onto the Barbecue Body (B1) as shown.

  • Page 15: Leak Testing

    Leak Test Diagram ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGES FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE. Leak test annually, and whenever the gas bottle is removed or replaced. Leak Testing Always perform a leak test in a well-ventilated area.

  • Page 16: Gas, Regulator And Hose

    5. Important Information  Use this barbecue only on a stable, flat surface. Please read these instructions carefully  Before you use your barbecue, perform a before assembly and use of your barbecue. leak test. This is the only safe and sure way to detect any gas leaking from joints and ...

  • Page 17: Installation

    7. Installation 1, Prior to opening the gas cylinder valve, make sure all BBQ control valves 7.1 Selecting a Location are in the “off” position. This barbecue is for outdoor use only and 2, Next open the gas cylinder valve , should be placed in a well-ventilated area, and opening the first half turn slowly before, then opening the gas tap fully .
  • Page 18 • To light the side burner, push and turn the 8.6 Griddle Plate Cooking The burners heat the griddle plate directly, control knob of the side burner to the high which then cooks the food on contact. Griddle position. Press the ignition button rapidly plates allow for the cooking of smaller items, several times until burner is lit.

  • Page 19: Care And Maintenance

    8.9 Flare-Up Control *VERY IMPORTANT minutes. This procedure will burn off cooking NOTICE* residue, thus making cleaning easier. Make sure Flare-ups occur when meat is barbecued, and the hood or lid is open during this process. its fat and juices fall upon the hot flame tamer. Smoke of course helps give food its barbecued 8.12 Turning Off Your Barbecue flavour, but it is best to avoid excessive flare-up...
  • Page 20 food debris can be removed from inside the mild cream cleaner on a non-abrasive pad. Do body using a soft plastic or wooden scraper. It is not use scouring pads or powders as they can not necessary to remove all the grease from the permanently damage the finish.

  • Page 21: Technical Specification

    MH4451 Gascraft 0359 17.28 Manta 0.84mm 2.75kPa 359CM1174 MH5651 2.94 0359 Side Burner 0.84mm 2.75kPa 359CM1174 Gas Consumption: Gascraft Talca-MH4451: 943g/hr Gascraft Manta-MH5651: 1258g/hr Side Burner: 214g/hr Min.Gas Supply Pressure:2.05kPa; Max.Gas Supply Pressure:3.45kPa Specifications subject to change without prior notice.

  • Page 22: Troubleshooting

    11. Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas Clean jets and gas hose hose Electrode or ignition button wire is...
