gascraft ODESSA 4 BURNER BBQ Manual

Hide thumbs

Advertisement

Table of Contents

ODESSA
4
BURNER BBQ
ODESSA
6
BURNER BBQ
Photographs are not to scale.
Specifications subject to change
without prior notice.
IMPORTANT!
ASSEMBLER: These instructions must be left with the user of the BBQ
for their reference. They contain important safety information required
for continued safe use of the BBQ.
WARNING
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
Retain these instructions for future reference.
Leak test your barbecue annually. Check the hose connections are tight and leak
test them each time you reconnect the gas bottle.
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
1008 18
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODESSA 4 BURNER BBQ and is the answer not in the manual?

Questions and answers

Related Manuals for gascraft ODESSA 4 BURNER BBQ

Summary of Contents for gascraft ODESSA 4 BURNER BBQ

  • Page 1 ODESSA BURNER BBQ ODESSA BURNER BBQ Photographs are not to scale. Specifications subject to change 1008 18 without prior notice. IMPORTANT! ASSEMBLER: These instructions must be left with the user of the BBQ for their reference. They contain important safety information required for continued safe use of the BBQ.

  • Page 2: Parts List

    Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. DELTA 4 BURNER BBQ ODESSA 4 BURNER BBQ Grill assembly Warming rack...
  • Page 3 Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. ODESSA 6 BURNER BBQ DELTA 6 BURNER BBQ Grill assembly Warming rack Cast iron cooking plate Cast iron cooking grill...

  • Page 4: Parts Diagram

    Parts Diagram Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. ODESSA 4 BURNER BBQ DELTA 4 BURNER BBQ...
  • Page 5 Parts Diagram Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. DELTA 6 BURNER BBQ ODESSA 6 BURNER BBQ...
  • Page 6 Hardware Reference Diagram Specifications subject to change without prior notice. M6X12mm Bolt 22pcs M6X35mm Bolt 10pcs M6 Nut 6pcs Axle Nut 2pcs M5*10 Bolt 6pcs Plastic Cap M4*10mm Bolt 1pcs 2pcs FLOOR AREA 2M X 2M 60 mins APPROXIMATE ASSEMBLY TIME 2 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS...

  • Page 7: Tools Needed For Assembly

    Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Philips/cross-point screwdriver, adjustable spanner or metric spanner set. This barbecue requires two people for assembly. Please remove all packaging materials from all individual parts before assembling. Please lay out all nuts and bolts and check lengths before assembling. Whilst every care is taken during the manufacture of this product, care must be taken during the assembly in case sharp edges are present.
  • Page 8 A * 6 E * 2 F * 1...
  • Page 9 A * 4 D * 2...
  • Page 10 B * 2 B * 4...
  • Page 11 Have half of the bolt threads go into the bolt holes. A * 8 Hang the side table and side burner assembly to the Grill assembly. Se- cure the bolts tightly by screwdriver after the alignment is done.
  • Page 12 Have half of the bolt threads go into the bolt holes. Secure the bolts tightly by screwdriver after the alignment is done. C * 3 Have half of the bolt threads go into the bolt holes. Secure the bolts tightly by screwdriver after the alignment is done.
  • Page 13 Loosen the two pre- assembled screws from the side burner valve bracket on the HVR of the Grill assembly. Fix the valve on the side burner control panel us- ing those two screws loosen.
  • Page 14 G * 2 Align the side burner venturi against the valve. Make sure the valve tip goes into the burner venturi completely with good alignment. Then tighten those two screws on the side burner after the alignment. Install the side burner electrode wire to the side burner electrode and igniter. Connect the black end to the electrode of the side burner assembly.
  • Page 15 Flame tamer must not be put under cooking plate.
  • Page 17 WARNING! ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE. Leak test annually, and whenever the gas bottle is removed or replaced.
  • Page 18 Important Information Failure to follow the manual’s instructions could result in serious injury or damage. Do not modify the appliance. Modification of this Please read this instructions fully before barbecue may be dangerous, is not permitted and using the appliance will nullify any warranty.

  • Page 19: Installation

    Operation Installation Warning Selecting a Location Before proceeding, make certain that you for outdoor use only understand the IMPORTANT INFORMATION This barbecue is and should be placed in a well-ventilated area, and on a safe section of this manual. and even surface. Never place your barbecue below Your barbecue is not designed to be used with ground level.
  • Page 20 Manual Ignition Instruction for Main Burner when handling anything near the cooking surface of the barbecue and take care to protect yourself from Insert lit match through the match-lighting hole at the flames. the side or bottom of the barbecue body. If a fat fire occurs, please see the instructions given Push in and turn the burner control knob anti- below.

  • Page 21: Care And Maintenance

    In the event of a fat fire Cooking Surfaces If safe to do so, turn all control knobs to the ‘off’ position. When the barbecue has cooled, clean with hot soapy water. To remove any food residue, use a mild cream Turn off the gas supply at the gas bottle.

  • Page 22: Technical Specifications

    Technical Specifications plastic or wooden scraper. It is not necessary to remove all the grease from the body. If you need to clean fully, use hot soapy water and a cloth, or nylon- bristled brush only. Do not use abrasives. Remove cooking surfaces and burners before full cleaning.
