Preface; Introduction; Document Layout - Microchip Technology EVB-LAN9252-DIG-IO User Manual

All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our web site
(www.microchip.com) to obtain the latest documentation available.
Documents are identified with a "DS" number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
"DSXXXXXA", where "XXXXX" is the document number and "A" is the revision level of the
document.
For the most up-to-date information on development tools, see the MPLAB
Select the Help menu, and then Topics to open a list of available online help files.

INTRODUCTION

This chapter contains general information that will be useful to know before using the
EVB-LAN9252-DIG-IO. Items discussed in this chapter include:

Document Layout

•
Conventions Used in this Guide
•
The Microchip Web Site
•
Development Systems Customer Change Notification Service
•
Customer Support
•
Document Revision History
•
DOCUMENT LAYOUT
This document describes how to use the EVB-LAN9252-DIG-IO as a development tool for the
Microchip LAN9252 EtherCAT® slave controller. The manual layout is as follows:
• Chapter 1. "Overview"
• Chapter 2. "Board Details & Configuration"
the EVB-LAN9252-DIG-IO.
• Chapter 3. "LAN9252 EEPROM Programming"
programming the LAN9252 EEPROM.
• Appendix A. "EVB-LAN9252-DIG-IO Evaluation Board"
EVB-LAN9252-DIG-IO.
• Appendix B. "EVB-LAN9252-DIG-IO Evaluation Board Schematics"
shows the EVB-LAN9252-DIG-IO schematics.
• Appendix C. "Bill of Materials (BOM)"
EVB-LAN9252-DIG-IO Bill of Materials (BOM).
 2014 Microchip Technology Inc.

Preface

NOTICE TO CUSTOMERS
– Shows a brief description of the EVB-LAN9252-DIG-IO.
Preliminary
EVB-LAN9252-DIG-IO
ETHERCAT® DIG I/O
USER'S GUIDE
®
– Includes details and instructions for using
– Includes details and instructions for
– This appendix shows the
– This appendix includes the
IDE online help.
– This appendix
DS50002332A-page 7
