Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
Introduction
The Model 727-001 Access Panel is a component of the SmartSeries ADVANCE system that can be used
for public address, intercommunication, and emergency notification.
How to Use the Assembly
Application
The Model 727-001 Desk Set Access Panel is used to communicate, initiate alarms and to control alarm
and paging destinations. It is equipped with a 120 V ac/240 V ac desktop power supply that allows the
access panel to be used in almost all installations without requiring additional line transformers.
The Model 727-001 Access Panel consists of the following main components:
27 configurable push buttons
A L
push button
T
AMP
EST
A total of 24 configurable LEDs available
Handset with pressbar
Speaker with volume control
Twenty-four of the 27 push buttons contain bi-color LED lamps that can be configured to provide system
status information.
The panel provides a handset equipped with an integral pressbar. The handset is used to make page
announcements and to hold two-way party line conversations. In addition, an internal speaker is provided
to allow page audio monitoring. The access panel also includes a volume control for the internal speaker.
: The speaker is disabled when the handset is in use.
N
OTE
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
V
ISIT WWW
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
Model 727-001
Desk Set Access Panel
610-777-1374 800-492-1212 Fax: 610-796-5954
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
Pub. 42004-690L2C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GAI-Tronics 727-001
Summary of Contents for GAI-Tronics 727-001
- Page 1 This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party. Introduction The Model 727-001 Access Panel is a component of the SmartSeries ADVANCE system that can be used for public address, intercommunication, and emergency notification.
-
Page 2: Hardware Configuration
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 2 of 10 The function of each of the 27 push buttons and 24 available LEDs is configurable using the GAI-Tronics ADVANCE system software. Hardware Configuration Figure 1. Model 727-001 Desk Set Access Panel Interfaces A 3-conductor ac power cord is included with the access panel. - Page 3 This connection allows the user to connect the power and the data/audio connection to the rear of the docking station to ease overall installation of the docking station. Figure 3. Model 727-001 Access Panel Typical Connections (Rear View) f:\standard ioms - current release\42004 instr. manuals\42004-690l2c.doc...
-
Page 4: Installation
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 4 of 10 Installation WARNING Please adhere to all warnings, safety, and operating instructions on the unit and in the installation manual. 1. Disconnect power before servicing. 2. Avoid servicing the unit during electrical storms. -
Page 5: Label Creation
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 5 of 10 Label Creation A Word 97 document is available to create custom slide-in labels for the desk set. It is available for download at www.gai.tronics.com. Follow the SmartSeries link, and select Access Panels. - Page 6 Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 6 of 10 Keypad Slide-In Labels To install the keypad slide-in labels, proceed as follows: 1. Separate the slide-in labels along the perforated lines on the sheet. 2. Fold the tab at the end of the slide-in label so that it is perpendicular to the reset of the label.
-
Page 7: Operation
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 7 of 10 Operation Operation of this assembly is highly dependent on the attached system’s software configuration. The software is factory-created and subsequently downloaded to the system control unit via an external PC at system start-up. -
Page 8: Servicing Guidelines
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 8 of 10 How to Diagnose Assembly Faults Servicing Guidelines 1. Notify plant personnel of a system shutdown prior to servicing the unit. 2. Disconnect power before connecting external wiring or installing or removing the access panel. -
Page 9: Specifications
Pub. 42004-690L2C Model 727-001 Desk Set Access Panel Page 9 of 10 Specifications Electrical Input voltage ........................120 V ac/240 V ac Auto-ranging Input frequency ..........................50/60 Hz Input current draw (with lamp test depressed) ..........60 mA @ 120 V ac, nominal... -
Page 10: Optional Accessories
51035-013 Replacement 28-Button Keypad 10119-001 Replacement Handset 61002-007 Replacement Line Cord Reference Material Reference to Assembly/Model Drawings Published by Title GAI-Tronics Ref. No. GAI-Tronics Model 727-001 Desk Set Access Panel Outline 73058 f:\standard ioms - current release\42004 instr. manuals\42004-690l2c.doc 03/13... -
Page 11: Warranty
If the services fail to meet the applicable industry standard, GAI-Tronics will re- perform such services at no cost to buyer to correct said deficiency to Company's satisfaction provided any and all issues are identified prior to the demobilization of the Contractor's personnel from the work site.
