2.0 Specifications

2.1 General Specifications

Circuit
Display
Measurements
Wire connections
Voltage ranges
Current ranges
Safety standard
ACV input impedance
Range select
Clamp frequency
response
Tested frequency
Over load protection
Over-range indicator
Under-range indicator
Data Hold
Data Recording
Sampling Time
Datalogger
Data Output
Operating Temp.
Operating R.H.
Power Supply
Power Consumption
Max. Conductor size
Distributed by MicroDAQ.com, Ltd.
Custom one-chip microprocessor LSI circuit
LCD Size: 81.4 X 61 mm (3.2 X 2.4")
Dot Matrix backlit LCD (320 X 240 pixels)
ACV / ACA / AC Watts (True Power)
AC Watts (Apparent Power)
AC Watts (Reactive Power)
Power factor
Phase angle
Frequency
1P/2W, 1P/3W, 3P/3W, 3P/4W.
10 ACV to 600 ACV (Auto Range)
0.2 ACA to 1200 ACA (Auto / Manual Range)
IEC1010 CAT III 600 V
10M ohms
ACV Auto Range
ACA Auto / Manual Range
40 Hz to 1 KHz
45 to 65 Hz
ACV 720 ACV RMS
ACA 1300 ACA with clamp probe
"OL"
"UR"
Freezes displayed reading
SD memory card
Approx. 1 second
Real time data logger saves data to SD memory card for download to
PC (data file opens directly to spreadsheet)
Sampling rate: 2 seconds to 7200 seconds
Serial or USB connection (cable supplied)
o
0 to 50 C (0 to 122
80% Relative Humidity max.
Eight (8) 'AA' 1.5VDC batteries or AC - DC 9V power adapter
Meter: 300 mA DC; Clamp: 20 mA DC
Clamp can accommodate up to 86 mm (3.4" ) diameter
