Electrical Specifications - Extech Instruments 382100 User Manual

Weight
Dimensions
Accessories Included

2.1 Electrical Specifications

ACV
Range
10.0V to 600.0V
Phase to neutral line
10.0V to 600.0V
Phase to phase
ACA
Range
20A
200A
1200A
Power Factor
Range
0.00 to 1.00
PFH (Power Factor Hours): Long Term Power Factor
For three phase/four wire and three phase/three wire configurations:
PF = (PF1 + PF2 + PF3) / 3
For single phase three wire configurations:
PF = (PF1 + PF2) / 2
Distributed by MicroDAQ.com, Ltd.
Meter: 1049g (2.3 lbs.) (with batteries); Clamp: 522g (1.2 lbs)
Meter: 225 X 125 X 64 mm (8.86 X 4.92 X 2.52")
Clamp: 210 X 64 X 33mm (8.3 X 2.5 X 1.3")
Clamp Jaw: 86 mm (3.4")
Instruction manual
Test Leads: 1 Set (4 pieces)
Alligator clips: 1 Set (4 pieces)
Clamp Probe (3)
AC to DC 9V adapter
SD card (2G)
Carrying case
Resolution
0.1V
Resolution
0.001A/0.01A
0.01A/0.1A
0.1A/1A
Resolution
0.01
6
www.MicroDAQ.com
Accuracy
± (0.5%+0.5V)
Accuracy
± (0.5%+0.1A)
± (0.5%+0.5A)
±(0.5%+5A)
Accuracy
± 0.04
382100-EU-EN v2.2 07/13
(603) 746-5524
