- Page 1 User’s Guide 600A AC Clamp Meter Model 38387 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Back to the Extech 38387 Product Info Page...
-
Page 2: International Safety Symbols
Safety International Safety Symbols This symbol, adjacent to another symbol or terminal, indicates the user must refer to the manual for further information. This symbol, adjacent to a terminal, indicates that, under normal use, hazardous voltages may be present Double insulation A UL mark does not indicate that this product has been evaluated for the accuracy of its readings. - Page 3 CAUTIONS • Improper use of this meter can cause damage, shock, injury or death. Read and understand this user manual before operating the meter. • Always remove the test leads before replacing the battery or fuses. • Inspect the condition of the test leads and the meter itself for any damage before operating the meter.
-
Page 4: Specifications
Specifications Function Range and Resolution Accuracy (of reading) AC Current 199.9 ACA ± (1.5% + 4 digits) 600 ACA @ 50/60Hz AC Voltage 600 VAC DC Voltage 600 VDC ± (1.0% + 1 digits) 1999 Ω Resistance ± (1.0% + 2 digits) Jaw size Opening 1.3"... -
Page 5: Meter Description
Meter Description Transformer jaws Data Hold button Peak Hold button LCD Display COM Input Terminal Jaw opening trigger Function select switch Voltage, Resistance Input Terminal Operation NOTICES: Read and understand all warning and precaution statements listed in the safety section of this operation manual prior to using this meter. - Page 6 AC Current Measurements WARNING: Ensure that the test leads are disconnected from the meter before making current clamp measurements. Set the Function switch to the 600 or 200A range. If the range of the measured is not known, select the higher range first then move to the lower range if necessary.
-
Page 7: Maintenance
Remove the three rear Phillips head screws Open the battery compartment Replace the 9V battery Re-assemble the meter 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Back to the Extech 38387 Product Info Page...
