BASIC SPECIFICATIONS

For complete specifications, please download the user manual.
Display
Over-range
indication
Battery power
Operating
temperature
Operating humidity
Dimensions
Weight
Safety
Agency approvals
Fuse types
Input impedance
AC bandwidth
AC response
Supplied
Thermocouple
#NAS100189; r. AD/96027/96066; en-US
Backlit LCD with bar graph
OL display
9 V battery
32 to 122℉ (0 to 50℃)
80% RH max. up to 87℉ (31℃)
7.2 x 3.3 x 2.2 in. (183 x 83 x 55 mm)
0.83 lbs. (375 g)
Meter: Over-voltage CAT IV 600 V, CAT III 1000 V, Pol-
lution Degree 2
Supplied test leads: Over-voltage CAT IV 600 V, CAT
III 1000 V
UL, CE, UKCA
800 mA (1000 V) ceramic fast blow (600 mA range)
10 A (1000 V) ceramic fast blow (10 A range)
> 10 MΩ (Voltage AC/DC); 2.5 to 3.5 kΩ (LoZ)
40 Hz to 1 kHz (AC voltage); 50/60 Hz (AC current)
True RMS (AC voltage/current)
Type K; rated 482℉ (250℃) maximum
8
