Direct connection of the base charging station (ISCAN201EXB) without plug connection to the power
supply with USB interface (ISCANPS2 or 4)
Connection base charging station USB ISCAN201CAB9 or 10 - Connection with cable end sleeves
Base charging station ISCAN201 USB
To fully operate the handheld ISCAN201 scanner you will require the programming information contained in
the manual published by SICK AG (www.SICK.com).
Operating Instructions_iSCAN201_001
RJ 45
Wire
Pin
colours
assignment
2
Green
10
White
7
Black
3
Brown
intrinsically safe connection box
of the ISCANPS2 or 4 power supply
after removal of the wires of the plug connection
Definition
Assignment
D+2SL
X9
D-2SL
X10
X11
GND
X12
+UB
X13
19
