Operating Manual

iSCAN X4C-2-P

iSCAN X4C-2-Q

Document Number X131609(1) (See DDM for the latest Version)

For warranty information, refer to Terms and Conditions at

http://www.extronics.com

Extronics reserve the right to change this manual and its contents without notice, the latest version

applies.

Table of Contents

Need help?

Do you have a question about the iSCAN X4C-2-P and is the answer not in the manual?

Questions and answers

Summary of Contents for extronics iSCAN X4C-2-P

Page 1 Document Number X131609(1) (See DDM for the latest Version) For warranty information, refer to Terms and Conditions at http://www.extronics.com ©2023 Extronics Limited. This document is Copyright Extronics limited. Extronics reserve the right to change this manual and its contents without notice, the latest version applies.
Page 2: Table Of Contents
Contents iSCANX4C-2 product range overview ..............3 Important notes on the operating instructions ............. 4 Safety information ..................4 Notes on the operating instructions ............... 4 General notes of caution ................5 Product Information ..................... 7 Manufacturer ....................7 Certification ....................7 Serial numbers ....................
Page 3: Iscanx4C-2 Product Range Overview
iSCANX4C-2 product range overview iSCANX4C-2-P iSCANX4C-2-Q Scanner handset iSCANX4C-CAB1 iSCANX4C-CAB3 iSCANX4C-CAB2 iSCANX4C-CAB4 USB comms cable RS232 comms cable iSCANPSCABR iSCANPSCABU Ex PSU - RS232 Ex PSU - USB...
Page 4: Important Notes On The Operating Instructions
The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Extronics Limited reserves the right to make changes to this document. Before they use the product, users must ensure that they have the most up-to-date version of the operating instructions.
Page 5: General Notes Of Caution
2.3 General notes of caution • The devices may only be operated when fully assembled. Caution / Notes • In hazardous areas, the devices must not be wiped or cleaned with a dry cloth. • The device must be switched off immediately if it is likely that it can no longer be operated safely as a result of damaging impact or general peculiarities (such as ingress of water or other fluids, temperatures outside of the specified range, etc.).
Page 6 Notes on • Electrical plants are subject to certain regulations concerning installation installation and operation (e.g. RL 99/92/EG, RL 94/9EG, or the national rules such as IEC 60 079-14 and VDE 0100). • In the hazardous area it is the operator's responsibility to carry out any repair and maintenance in compliance with applicable rules.
Page 7: Product Information
Product Information 3.1 Manufacturer Extronics Limited 1 Dalton Way Midpoint 18 Middlewich CW10 0HU 3.2 Certification iSCANX4C-2-P: II 3G Ex ic IIC T4 Gc II 3D Ex ic IIIC T135C Db iSCANX4C-2-Q: II 3G Ex ic IIB T4 Gc II 3D Ex ic IIIC T135°C Dc...
Page 8: Technical Data
3.4 Technical data iSCANX4C-2-P: • maximum input voltage 6.5 V • maximum internal negligible inductance • maximum internal <141 µF capacitance iSCANX4C-2-Q: • maximum input voltage 6.5 V • maximum internal negligible inductance • maximum internal <374 µF capacitance • maximum voltage Supply 253 V AC iSCANPSCABx:...
Page 9: Iscanx4C-2-P
Technical Data iSCANX4C-2-P: (Scan engine) • Light source Visible red light 630nm • LED safety LED classification acc. to DIN EN 60825-1 • Scan rate 500 scans per second • Reader 20 to 850mm distance iSCANX4C-2-Q: • LED lighting Visible red light 630nm •...
Page 10: System Assembly
System assembly 4.1 Assembly description – USB The wired handheld scanner was designed for use in Zone 2/22 hazardous areas. Normal operation requires a power supply, a connection cable between power supply and scanner, and connection cable(s) between power supply. For a connection to the PC in the non-hazardous area, a mini USB plug is attached to the USB supply line so that the cable can be routed through a cable gland.
Page 11: Assembly Description - Rs232
4.2 Assembly description - RS232 The wired handheld scanner was designed for use in Zone 2/22 hazardous areas. Normal operation requires a connection cable between wired handheld scanner zone 2/22 and the supply and or the supply line. For connection to the PC in the non-hazardous area, the RS232 supply cable is equipped with individual cores so that the cable can be routed through a cable gland.
Page 12: Cable Range
4.3 Cable range 2.0m (straight) RS232 iSCANPSCABR Up to 15m Host iSCANX4C-2-P or 3.6m (spiral) iSCANX4C-2-Q 2.0m (straight) iSCANPSCABU Up to 5m Host or 3.6m (spiral) 4.4 Cable lengths of the supply cable Scanner side 0,2 m Host connection: 3 m RS232 Scanner side 0,2 m Host connection 3 m...
Page 13: Step By Step Guide - Installation And Operation
Step by step guide - installation and operation 5.1 General connection of handheld scanner Insert the RJ45 plug of the cable connecting the handheld scanner with the power supply at the bottom of the scanner. Make sure the plug has engaged fully. Cable connected to the wired handheld scanner Insert the plug of the connection cable into the power supply's plug connector.
Page 14: Connection Of Rs232 And Usb Iscanpscabx Power Supply
5.2 Connection of RS232 and USB iSCANPSCABx power supply USB interface Caution: Do not open the housing. Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened. Changes at the pin assignment may only be made by trained personnel.
Page 15 Supply and data transfer with USB interface to the higher-level system outside the hazardous area Ex e connection Supply cable Type: iSCANPSCABU wires Definition Mini USB Pin + UB 1 (red) 2 (white) 3 (green) 5 (black) There is an adapter from mini USB to USB A included. If the supply voltage of the USB interface is not able to supply a current >...
Page 16 RS232 Interface Attention! Do not open the housing! Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened. Changes at the pin assignment may only be made by trained personnel.
Page 17 Supply and data transfer with RS232 interface to the higher-level system outside the hazardous area Ex e connection Supply line type: iSCANPSCABR wires 9 pole Sub-D wire definition RS232 Pin 1 (white) TxD / RS232 2 (brown) GND / RS232 3 (yellow) TxD + / RS422 4 (green)
