extronics iSCAN X4B-2-P Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Manual
iSCAN X4B-2-P
iSCAN X4B-2-Q
X131546(1)
Document Number
(See DDM for the latest Version)
For warranty information, refer to Terms and Conditions at
http://www.extronics.com
©2020 Extronics Limited. This document is Copyright Extronics limited.
Extronics reserve the right to change this manual and its contents without notice, the
latest version applies.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSCAN X4B-2-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for extronics iSCAN X4B-2-P

Summary of Contents for extronics iSCAN X4B-2-P

  • Page 1 (See DDM for the latest Version) For warranty information, refer to Terms and Conditions at http://www.extronics.com ©2020 Extronics Limited. This document is Copyright Extronics limited. Extronics reserve the right to change this manual and its contents without notice, the latest version applies.

  • Page 2: Table Of Contents

    Contents iSCAN X4B-2 product range overview ................ 3 Important notes on the operating instructions ............. 4 Safety information ..................4 Notes on the operating instructions ............... 4 General notes of caution................5 Product Information ....................7 Manufacturer ....................7 Certification ....................7 Serial numbers ....................

  • Page 3: Iscan X4B-2 Product Range Overview

    1 iSCAN X4B-2 product range overview iSCANX4B-2-P iSCANX4B-2-Q Scanner Handset iSCANX4B-2-BS iSCANX4B-2-EXBS iSCANX4B-2-CS Ex Base station Non-Ex Base station iSCANX4B-CAB5 iSCANX4B-CAB9 iSCANX4B-CAB1 iSCANX4B-CAB3 iSCANX4B-CAB6 iSCANX4B-CAB10 iSCANX4B-CAB2 iSCANX4B-CAB4 RS232 comms cable USB comms cable RS232 comms cable USB comms cable iSCANPSCABR iSCANPSCABU iSCANX4B-BSP Ex Supply cable - RS232...

  • Page 4: Important Notes On The Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Extronics Limited reserves the right to make changes to this document. Before they use the product, users must ensure that they have the most up-to-date version of the operating instructions.

  • Page 5: General Notes Of Caution

    2.3 General notes of caution Caution / • The devices may only be operated when fully assembled. Notes • In hazardous areas, the devices must not be wiped or cleaned with a dry cloth. • The device must be switched off immediately if it is likely that it can no longer be operated safely as a result of damaging impact or general peculiarities (such as ingress of water or other fluids, temperatures outside of the specified range, etc.).

  • Page 6: Installation

    Notes on • Electrical plants are subject to certain regulations concerning installation installation and operation (e.g. RL 99/92/EG, RL 94/9EG, or the national rules such as IEC 60 079-14 and VDE 0100). • In the hazardous area it is the operator's responsibility to carry out any repair and maintenance in compliance with applicable rules.

  • Page 7: Product Information

    3 Product Information 3.1 Manufacturer Extronics Limited 1 Dalton Way Midpoint 18 Middlewich CW10 0HU 3.2 Certification II 3G Ex ic IIB T4 Gc II 3D Ex ic IIIC T135C Dc Test certificate IBExU19ATEXB010 X IECEx IBE 19.0023X Protection rating IP65 3.3 Serial numbers...

  • Page 8: Technical Data

    Scanning frequency iSCAN X4B-2-P: 500Hz iSCAN X4B-2-Q: 60Hz Light Source Visible red light 630 nm Reading distance iSCAN X4B-2-P: 20 to 850mm iSCAN X4B-2-Q: 30 to 400mm User feedback signals 2 LEDs (operation status and read feedback) Audio beeper Vibration...

  • Page 9: Technical Data For Base/Charging Station

    3.5 Technical data for base/charging station The base charging station iSCANX4B-2-EXBS may be operated in hazardous areas. Its purpose is to receive data captured by the associated handheld scanner via bluetooth • maximum input voltage Nominal values of 6,5 V hazardous area base •...

  • Page 10: System Assembly

    4 System assembly 4.1 System example 1 The Bluetooth handheld scanner was designed for use in hazardous areas. Normal operation requires a base station, a power supply cable and a connection cable between the two. For iSCANPSCABU, a mini USB plug is attached to the USB-supply cable so that the cable can be routed through a cable gland.

  • Page 11: Cable Lengths In Example 1

    4.2 Cable lengths in example 1 2.0m (straight) RS232 iSCANPSCABR Up to 15m or 3.6m (spiral) iSCANX4B- Host 2-EXBS 2.0m (straight) iSCANPSCABU Up to 5m or 3.6m (spiral) 4.3 System example 2 The Bluetooth handheld scanner can also be used separately in the hazardous area. The base or charging station is then operated in the non-hazardous area.

  • Page 12: Cable Lengths Of The Supply Cable

    4.5 Cable lengths of the supply cable Scanner side 0,2 m Host connection: 3 m RS232 Scanner side 0,2 m Host connection 3 m...

  • Page 13: Step-By-Step Guide, Installation And Operation

    5 Step-by-step guide, installation and operation 5.1 General connection of handheld scanner Do not replace the battery in hazardous areas. Incorrect handling may result in the termination of the operating permit. The battery compartment is located at the bottom of the Bluetooth handheld scanner.

  • Page 14: Using The Base Station In Hazardous Areas (Example 1)

    5.2 Using the base station in hazardous areas (Example 1) The device has been closed ex-factory. Incorrect handling may result in the termination of the operating permit. The cable connecting the base charging station to the power supply is iSCANX4B-CAB5, 6, 7, 8, 9 or 10. Insert the cable in the opening at the bottom of the base charging station.

  • Page 15: Using The Base Station In Non-Hazardous Areas (Example 2)

    5.3 Using the base station in non-hazardous areas (Example 2) Charge the handheld scanner in the safe area with a non-explosion-protected base charging station. Use a safe area power supply for supply to the base charging station. The cable is inserted in the corresponding opening at the bottom of the base charging station.

  • Page 16: Pin Assignment Of Iscanpscabr

    5.4 Pin assignment of iSCANPSCABR Supply of the base charging station zone 2/22 with plug connection – plug/coupling Caution! Do not open this enclosure! Before operating the device in hazardous area you have to ensure that the housing has been closed fully and is not damaged.
  • Page 17 Supply and data transmission with RS232 interface to the higher-level system outside the hazardous area Supply cable Ex e connection Wire 9 pin Sub-D RS232 wire Definition 1 (white) TxD / RS232 2 (brown) GND / RS232 3 (yellow) TxD + / RS422 4 (green) TxD - / RS422 5 (grey)

  • Page 18: Pin Assignment Of Iscanpscabu

    5.5 Pin assignment of iSCANPSCABU Supply of the base charging station zone 2/22 with plug connection – plug/coupling Caution! Do not open this enclosure! Before operating the device in hazardous area you have to ensure that the housing has been closed fully and is not damaged.
  • Page 19 Supply and data transfer with USB interface to the higher-level system outside the hazardous area Ex e connection Supply cable wire Definition Mini USB Pin + UB 1 (red) 2 (white) 3 (green) 5 (black) There is an adapter from mini USB to USB A included. If the supply voltage of the USB interface is not able to supply a current>...
