Operating Manual
iSCAN X4C-1-P
iSCAN X4C-1-Q
Document Number X131608(1) (See DDM for the latest Version)
For warranty information, refer to Terms and Conditions at
http://www.extronics.com
©2023 Extronics Limited. This document is Copyright Extronics limited.
Extronics reserve the right to change this manual and its contents without notice, the latest version
applies.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the iSCAN X4C-1-P and is the answer not in the manual?

Questions and answers

Summary of Contents for extronics iSCAN X4C-1-P

  • Page 1 Document Number X131608(1) (See DDM for the latest Version) For warranty information, refer to Terms and Conditions at http://www.extronics.com ©2023 Extronics Limited. This document is Copyright Extronics limited. Extronics reserve the right to change this manual and its contents without notice, the latest version applies.
  • Page 2: Table Of Contents

    Contents iSCANX4C-1 product range overview ..............3 Important notes on the operating instructions ............. 4 Safety information ..................4 Notes on the operating instructions ............... 4 General notes of caution ................5 Product Information ..................... 7 Manufacturer ....................7 Certification ....................7 Serial numbers ....................
  • Page 3: Iscanx4C-1 Product Range Overview

    iSCANX4C-1 product range overview iSCANX4C-1-P iSCANX4C-1-Q Scanner handset Scanner handset iSCANX4C-CAB1 iSCANX4C-CAB3 iSCANX4C-CAB1 iSCANX4C-CAB3 iSCANX4C-CAB2 iSCANX4C-CAB4 iSCANX4C-CAB2 iSCANX4C-CAB4 RS232 comms cable USB comms cable RS232 comms cable USB comms cable iSCANPS1 iSCANPS2 iSCANPS5 iSCANPS6 iSCANPS3 iSCANPS4 iSCANPS7 iSCANPS8 Ex PSU - RS232 Ex PSU - USB Ex PSU - RS232 Ex PSU - USB...
  • Page 4: Important Notes On The Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Extronics Limited reserves the right to make changes to this document. Before they use the product, users must ensure that they have the most up-to-date version of the operating instructions.
  • Page 5: General Notes Of Caution

    2.3 General notes of caution • The devices may only be operated when fully assembled. Caution / Notes • In hazardous areas, the devices must not be wiped or cleaned with a dry cloth. • The device must be switched off immediately if it is likely that it can no longer be operated safely as a result of damaging impact or general peculiarities (such as ingress of water or other fluids, temperatures outside of the specified range, etc.).
  • Page 6 • Electrical plants are subject to certain regulations concerning Notes on installation installation and operation (e.g. RL 99/92/EG, RL 94/9EG, or the national rules such as IEC 60 079-14 and VDE 0100). • In the hazardous area it is the operator's responsibility to carry out any repair and maintenance in compliance with applicable rules.
  • Page 7: Product Information

    Product Information 3.1 Manufacturer Extronics Limited 1 Dalton Way Midpoint 18 Middlewich CW10 0HU 3.2 Certification iSCANX4C-1-P: II 2 G Ex ib IIB T4 Gb II 2 D Ex ib IIIC T135C Db iSCANX4C-1-Q: II 2G Ex ib op is IIB T4 Gb II 2D Ex ib op is IIIC T135°C Db...
  • Page 8: Technical Data

    3.4 Technical data • maximum input voltage iSCANX4C-1-P: 4.9 V • maximum input current 480 mA • maximum input power 1.25 W • maximum internal negligible inductance • maximum internal 141 µF capacitance If using a power supply other than iSCANPSX: •...
  • Page 9: Iscanx4C-1-P

    Technical Data iSCANX4C-1-P: (Scan engine) • Light source Visible red light 630nm • LED safety LED classification acc. to DIN EN 60825-1 • Scan rate 500 scans per second • Reader 20 to 850mm distance iSCANX4C-1-Q: • LED lighting Visible red light 630nm •...
  • Page 10: System Assembly

    System assembly 4.1 Assembly description The wired handheld scanner was designed for use in hazardous areas. Normal operation requires a power supply, a connection cable between power supply and scanner, and connection cable(s) between power supply and a PC. External connection cables: Data cable: USB 0.2 - 2.5 mm², 4-wire RS232 0.2 - 2.5 mm², 3-wire...
  • Page 11: Step By Step Guide - Installation And Operation

    Step by step guide - installation and operation 5.1 General connection of handheld scanner Insert the RJ45 plug of the cable connecting the handheld scanner with the power supply at the bottom of the scanner. Make sure the plug has engaged fully. Cable connected to the wired handheld scanner Insert the plug of the connection cable into the power supply's plug connector.
  • Page 12: Connection Of Rs232 Iscanpsx Power Supply

    5.2 Connection of RS232 iSCANPSX power supply The terminal assignment is located underneath the removable cover at the front of the power supply. Caution: Do not open enclosure in the hazardous area. Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened.
  • Page 13: Direct Connection Of Scanner W/O Plug To The Rs232 Iscanpsx

    5.3 Direct connection of scanner w/o plug to the RS232 iSCANPSx Pin assignment of RS232 connection cable Power supply scanner (iSCANX4C-CAB1, 2) (iSCANPS1, 3, 5, 7) RJ45 Pin Wire Definition Connection Definition assignment colours terminal power supply White Brown Yellow Intrinsically safe connection box of the RS232 iSCANPSX power supply after removal of the wires of the plug...
  • Page 14: Connection Of Usb Iscanpsx Power Supply

    5.4 Connection of USB iSCANPSX power supply The terminal assignment is located underneath the removable cover at the front of the power supply. Caution: Do not open enclosure in the hazardous area. Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been tightened.
  • Page 15: Direct Connection Of Scanner W/O Plug To The Usb Iscanpsx

    5.5 Direct connection of scanner w/o plug to the USB iSCANPSx Pin assignment of USB connection cable Power supply scanner (iSCANX4C-CAB3, 4) (iSCANPS2, 4, 6, 8) RJ45 Pin Wire Definition Connection Definition assignment colours terminal power supply Green White Black Brown Intrinsically safe connection box of the USB iSCANPSX power supply...

This manual is also suitable for:

Iscan x4c-1-q
