  • Page 1 User Manual Bluetooth Handheld Scanner iSCAN201 Date: 27.03.2015...

  • Page 2: Table Of Contents

      4 Step-by-step guide on installation and operation ..................12   4.1 Preparation handheld iSCAN201 scanner for system assembly 1 and 2 ............ 12   4.2 Using the base charging station for system assembly 1 (hazardous areas) ..........14  ...

  • Page 3: Important Notes On The Operating Instructions

    1 Important notes on the Operating Instructions 1.1 Safety information Warnings are highlighted by a special symbol and a different font colour: Non-compliance may result in life-threatening situations. This warning must be heeded. Danger This type of warning concerns dangerous situations that may result in minor injuries. Warning Important and helpful notes and information.

  • Page 4: Notes On The Operating Instructions

    The notes contained in this manual are important for starting up and operating the product. These instructions may be updated at any time. Extronics Limited reserves the right to make changes to this document.

  • Page 5: General Notes Of Caution

    1.3 General notes of caution Caution / Notes  The devices may only be operated when fully assembled.  In hazardous areas, the devices must not be wiped or cleaned with a dry cloth.  The device must be switched off immediately if it is likely that it can no longer be operated safely as a result of damaging impact or general peculiarities (such as ingress of water or other fluids, temperatures outside of the specified range, etc.).
  • Page 6 Caution Devices fitted with laser fall under standards US 21 CFR 1040.10 and EN on laser devices 60825-1. The laser's classification is stated on a plate affixed to the device. Class 1 lasers are deemed inherently safe during normal use, but users must not look directly into the light source.

  • Page 7: Product Information

    2 Product information Extronics Limited 2.1 Manufacturer 1 Dalton Way Midpoint 18 Middlewich, UK CW10 0HU Device iSCAN201 II 2G Ex ib IIC T4 2.2 Explosion protection II 2G Ex ib IIC T4 Gb II 2D Ex ib IIIC T135C II 2D Ex ib IIIC T135C Db...

  • Page 8: Base Charging Station Technical Data

    2.4 Base charging station technical data Ambient temperature -20°C to +50°C Base charging station Bluetooth Bluetooth V 2.1 EDR, Class 2 Base charging station 2.4 ... 2.4835 GHz (ISM band) Terminal assignment USB cable RS 232 cable (Base charging station) USB/D+ green RS 232-TXD white USB/D- white...

  • Page 9: Components

    2.5 Components iSCAN201 Standard version iSCAN201PDF Stacked PDF version Both are for use with the battery ISCAN201BATT and a base charging station of your choice (see below) With an explosion-protected connection cable USB/RS232 or a non-explosion-protected connection cable USB/RS232 and a power supply ISCANPS, depending on voltage and interface...

  • Page 10: System Assembly

    Description: The Bluetooth handheld iSCAN201 was designed for use in hazardous areas. Normal operation requires a base charging station, a connection cable between the base charging station and the iSCANPS power supply, and a connection cable between the power supply and a PC.

  • Page 11: System Assembly 2

    Description: The Bluetooth handheld iSCAN201 scanner can also be used separately in the hazardous area. The base charging station is then operated in the non-hazardous area. Use an RS232 cable or a USB cable to connect the station directly to a power supply and a PC.

  • Page 12: Cable Range In System Assembly 1

    3.3 Cable range in system assembly 1 1,8 or 3,8m iSCAN201 optional with 4,5m RS232 Base charging iSCANPS Up to 20m Host or 6m station extension iSCAN201 Base charging 1,8 or 3,8 m iSCANPS Up to 5m Host station 3.4 Cable range in system assembly 2...

  • Page 13: Step-By-Step Guide On Installation And Operation

    4 Step-by-step guide on installation and operation 4.1 Preparation handheld iSCAN201 scanner for system assembly 1 and 2 Do not replace batteries in hazardous areas. Incorrect handling may result in the termination of the operating permit. The battery compartment is located at the bottom of the scanner.
  • Page 14 Insert the battery into the battery compartment of the scanner. The end of the removal strap must be protrude from the opening. If the battery has been correctly inserted and connected to the contacts, this will be indicated by an acoustic and a visible signal.

  • Page 15: Using The Base Charging Station For System Assembly 1 (Hazardous Areas)

    Ensure that the connection is fully secured with the screw cap after the plug has been inserted. Place the iSCAN201 handheld scanner onto the charging station. Insert the lower part of the handle to ensure that the contacts for charging are connected properly.

  • Page 16: Using The Base Charging Station For System Assembly 2 (Non-Hazardous Areas)

    If the cable has been inserted fully you can hear a "click". Check that the cable fits firmly. Place the ISCAN201 handheld scanner onto the charging station. Insert the lower part of the handle to ensure that the contacts for charging are connected properly.

  • Page 17: Pin Assignment Power Supply With Rs232 Interface

    4.4 Pin assignment power supply with RS232 interface Supply of the base charging station according to system assembly 1 with plug connection The pin assignment is located underneath the removable cover at the front of the power supply. Caution! Do not open enclosure in the hazardous area! Before operating the device in a hazardous area you have to ensure that the enclosure has been closed fully and all screws have been...
  • Page 18 ISCANPS1 or 3 power supply after removal of the wires of the plug connection To fully operate the handheld ISCAN201 scanner you will require the programming information contained in the manual published by SICK AG (www.SICK.com).

  • Page 19: Pin Assignment Power Supply With Usb Interface

    4.5 Pin assignment power supply with USB interface Supply of the base charging station according to system assembly 1 - with plug connection The terminal assignment is located underneath the removable cover at the front of the power supply. Caution: Do not open enclosure in the hazardous area.
  • Page 20 ISCANPS2 or 4 power supply after removal of the wires of the plug connection To fully operate the handheld ISCAN201 scanner you will require the programming information contained in the manual published by SICK AG (www.SICK.com). Operating Instructions_iSCAN201_001...

  • Page 21: Attachment

    5 Attachment 5.1 EC type examination certificate: ISCAN201 and ISCAN201 base charging station Operating Instructions_iSCAN201_001...
  • Page 22 Operating Instructions_iSCAN201_001...

  • Page 23: Ec Type Examination Certificate: Power Supply Iscanps

    5.2 EC type examination certificate: Power supply ISCANPS Operating Instructions_iSCAN201_001...
  • Page 24 Operating Instructions_iSCAN201_001...
  • Page 25 Operating Instructions_iSCAN201_001...
  • Page 26 Operating Instructions_iSCAN201_001...

  • Page 27: Contact

    6 Contact Extronics Limited 1 Dalton Way Midpoint 18 Middlewich Cheshire Tel. +44 (0) 845 277 5000 Fax +44 (0) 845 277 4000 info@extronics.com Operating Instructions_iSCAN201_001...
