Portwell ROBO-598 User Manual

Introduction
CHAPTER 1
Introduction
The ROBO-598 all-in-one single board computer is designed to fit a high
performance Pentium-based CPU and compatible for high-end computer system with
AGP and PCI Local Bus architecture. It is made to meet today's demanding pace,
and keep complete compatibility with hardware and software designed for the IBM
PC/AT. It's beneficial to build up a high performance and high data availability
system for VARs, or system integrators. The on-board AGP (Accelerated Graphics
Port) graphics display will bring 3D performance to all segments of the PC market.
This single board computer can run with Intel Pentium or compatible processor up to
400 MHz, and support DIMM up to 768MB DRAM. The enhanced on-board PCI
IDE interface can support 4 drives up to PIO mode 5 timing and Ultra 33
synchronous DMA - Mode 2 transfer. The general Super I/O function by built-in
South Bridge Chipset integrates floppy controller, two serial ports, one FIR (Fast
Infra Red) port and one parallel port. Two high performance 16C550-compatible
UARTs provide 16-byte FIFOs, and the multi-mode parallel port supports
ECP/EPP/SPP function. Besides, two USB (Universal Serial Bus) ports provide
high-speed data communication between peripherals and PC.
The PICMG standard makes the ROBO-598 works with the legacy ISA, ISA/PCI or
pure multi-PCI backplanes. The on board 32-pin DIP socket supports M-system
Disk-On-Chip products up to 72MB. The Watch-Dog Timer function can monitor
your system status. Two 6-pin Mini-DIN connectors are provided to connect PS/2
Mouse and Keyboard. The on board Flash ROM is used to make the BIOS update
easier. A standard P8 power connector is reserved to directly get more power
energy for big power applications, and the additional 5-pin shrouded connector is
reserved for connecting Keyboard interface on the backplane. The high precision
Real Time Clock/calendar is built in for accurate scheduling and storing
configuration information. All these features make ROBO-598 excellent in stand-
alone applications.
ROBO-598 User's Manual
1-1
