THE SETTINGS MODE
The console features a settings mode that allows you
to select a unit of measurement for the console and to
view console usage information.
To select the settings mode,
press and hold down the Watts
Workouts button until the settings
mode information appears in the
display.
J
q,,
TIME
The console can show pedaling speed and distance in
either miles or kilometers. The lower display will show
the selected unit of measurement. An E for English
miles or an M for metric kilometers will appear in the
display. To change the unit of measurement, press the
Resistance increase button repeatedly.
Note: When you replace the batteries, it may be neces-
sary to reselect the unit of measurement.
The center display will show the total distance (in miles
or kilometers) that the exercise bike has been pedaled
and the total time (in hours) that the console has been
used since the exercise bike was purchased. Press the
Calorie Workouts button repeatedly to view the total
distance and the total time.
To exit the settings mode, press the Watts Workouts
button.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: To assure continued
compliance,
use only shielded
interface cables when connecting to
computer or peripheral devices. Changes or modifications
not expressly approved
by the party respon=
sible for compliance
could void the user's authority
to operate this equipment.
18
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the 460R and is the answer not in the manual?
Questions and answers
where do you change the battery
To change the battery on a Pro-Form 460R, unscrew the latch behind the display screen and replace the old batteries with heavy-duty alkaline D batteries.
This answer is automatically generated
Dont see the pedal crank arm in the parts list
The pedal crank arm is part of the "Crank/Pulley" assembly, which is listed as item 40 in the parts list for the Pro-Form 460R.
This answer is automatically generated
how to remove the pedal crank arm?
To remove the pedal crank arm on a Pro-Form 460R:
1. Using an adjustable wrench, turn the Right Pedal (29) counterclockwise to remove it.
2. Use a flat screwdriver to release the tabs around the edge of the right Lock Ring (23) and remove it from the Right Shield (22).
3. Once the Drive Belt (59) is tight, tighten the Adjustment Screw (47).
4. Remove the Rear and Front Upright Covers (19, 20) by removing the two M4 x 12mm Screws (57).
5. Reattach the necessary parts after removal.
Note: The crank arm itself is not directly mentioned, but these steps involve removing the pedal and surrounding components, which may be necessary for crank arm removal.
This answer is automatically generated
replaced batteries and no power up response after pedaling up. Can you advise? Unit incline 460R smr proform incline bicycle
