SBC8232 386SX ISA Half-size CPU Card Family User's Manual
2.1

Jumper Settings

2.1.1 CPU Speed Select (JP6)

Options
16.7MHz
25MHz
33.3MHz
40MHz

2.1.2 Reset/HDD LED (J2, 11-18)

Options
System reset switch
HDD LED, Pin18+, Pin17-

2.1.3 Watchdog Function Select (JP4)

Watchdog time out gen. system reset

2.1.4 External Keyboard (J3)

Options
Keyboard clock
Keyboard data
No connect
Keyboard Ground
Keyboard Power

2.1.5 Speaker/Keylock/Power LED (J2, 1-10)

Options
Internal buzzer
External speaker (remove 1-3)
Power LED, Pin 2+, Pin6-
Keylock
6
Settings
Short 1-2, 3-4
Open
Short 3-4
Short 1-2
Settings
Short 11-12
Short 17-18
Options
Settings
1
2
3
4
5
Settings
Short 1-2
Settings
Short 1-3
Short 1-7
Short 2-6
Short 8-10
Jumpers and Connectors
