2.1.11 AT Keyboard/PS2 Mouse Selection(JP1)

Options
AT Keyboard
PS/2 Mouse
2.2

Connectors

The connectors allow the CPU card to connect with other parts
of the system. Some problems encountered with your system
may be caused by loose or improper connections. Ensure that
all connectors are in place and firmly attached.
Component
HDD (IDE) connector
FDD connector
Parallel port
PC/104 connector
Keyboard connectors
Reset switch connector
External speaker connector
HDD LED connector
External power connector
Serial port1
Serial port2
VGA connector
CMOS RAM clear
8
JP1
Short 3-5, 4-6
Short 1-3, 2-4
Label
IDE
FDC
PRN
PC104
J4, J3
J2 (11-12)
J2 (1-7)
J2 (17-18)
J1
COM1
COM2
VGA
JP7
Jumpers and Connectors
