SBC8232 386SX ISA Half-size CPU Card Family User's Manual
3.2

Completing the Installation

To complete the installation, the following steps should be
followed:
1. Make sure the power is off.
2. Set the configuration jumpers in accordance with
Chapter 2.
3. Install the SBC8232V CPU card into one of the slots
in a passive backplane. Or, just take the SBC8232V
alone as a single board computer.
4. Connect the applicable I/O cables and peripherals,
i.e. floppy disk, hard disk, monitor, keyboard,
power supply and etc.
NOTE:
The color of pin one is usually red or blue, while
others are gray.
5. Turn on the power.
10
