- Page 1 HDS-21RS Owner’s Manual 2 x 1 HDMI Switch with Scaling PureLink E-mail: info@purelinkav.com 535 East Crescent Avenue www.purelinkav.com Ramsey, NJ 07446, USA Tel: 201.488.3232 For technical support, contact: Fax: 201.621.6118 support@purelinkav.com...
-
Page 2: Table Of Contents
Table of Contents 1-1 Package Contents 1-2 General Specification 1-3 Operation and Reliability Specifications 1-4 Main Features 1-5 Operation Guide & Mechanical Specification 1-8 Warranty Information p.13 1-9 Troubleshooting p.14... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) HDS-21RS Unit 2) DC 5V 1A Power supply adapter 3) Owner’s Manual 4) Remote controller... -
Page 4: General Specification
This manual contains information that will assist you in installing and operating the product. PureLink HDS-21RS HDMI switch allows two HDMI/DVI sources (with audio) to share one display. Our unique switch allows easy switching between different digital video sources with remote control unit and/or with a manual toggle button in front and/or via RS232 port. - Page 5 PureLink by Dtrovision Dimension (WxDxH) 2.76” x 5.51” x 0.98” (70 x 140 x 25 mm) Weight 0.66 lbs (0.3 kg) Connector Pin Assignment Part No. Pin No. Description Remarks TMDS DATA 2P TMDS DATA 2 Shield TMDS DATA 2M...
-
Page 6: Operation And Reliability Specifications
PureLink by Dtrovision 1-3 Operation and Reliability Specification 1. Operating Environment Temperature : 32F ~ 104F (0℃~ 40℃) Humidity : 20% ~ 90% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃) Humidity : 5% ~ 95% Altitude : 15,000m Max. -
Page 7: Main Features
1-4 Main Features 1. High Quality Picture - No Signal Loss and Digital Noise Free HDS-21RS is built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 8: Operation Guide & Mechanical Specification
5. Plug the 5V wall mount power supply into the wall outlet 6. Turn on HDS-21RS 7. Turn on your monitor 8. Turn on your video source Mechanical Specification HDS-21RS dimension (WxDxH): 2.76’’ x 5.51’’ x 0.96’’ (70 x 146 x 25mm) 0.66 lbs (0.3 kg) - Page 9 HDMI IN 2: HDMI Input 2 HDMI OUT: HDMI Output RS232: For RS232 control Operation Guide Input Switching Two active sources can be connected to the HDS-21RS at the same time. There are three ways to switch inputs. 1. Front panel button INPUT toggle button...
-
Page 10: Input 1 Button For Input
Data bits – 8 Parity – none Stop bits – 1 MODE There are total 4 output mode options in HDS-21RS. Mode 1 One full input image output mode Mode 2 Picture in picture image output mode... -
Page 11: Mode
1080p@60Hz Timing 2 720p@60Hz Timing 3 1080i@60Hz Timing 4 1360x768@60Hz Timing 5 1024x768@60Hz Command Line Operation This section is designed for programmers who wish to create their own control programs using the command code. HDS-21RS provides a simple character stream... -
Page 12: Data Bits
PureLink by Dtrovision control used by external control devices attached to a PureLink device. Command codes are used primarily for control, during system installation, setup, and for diagnostic purposes. Command code is a set of alphanumeric characters that combine to form control commands. - Page 13 1-8 Warranty 3 (three) Year Warranty Dtrovision warrants this PureLink UHD-280 to be free from defects in workmanship and materials, under normal use and service, for a period of two (3) year from the date of purchase from Dtrovision or its authorized resellers.
-
Page 14: Troubleshooting
To extend beyond 20ft, please use fiber optical HDMI extension cables such as PureLink EZ series. 3. Use high quality HDMI cables. 4. If you are using computers, try other refresh rate settings. - Page 15 PureLink by Dtrovision FCC/CE Statement This device complies with part 15 of FCC Rules and EN 55022/55024/61000-3 for CE certification. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must not accept any interference received, including interference that may cause undesired operation.
