60kHz. The IR receiver cable included with the package, however, only supports signals from 30kHz to 56 kHz. Features may have been added to the VE882 / VE892 since this manual was published. Please visit our website to download the most up-to-date version of the manual.
Page 6
3.125 Gbps optical link (for resolutions up to 1080p@60Hz with 24-bit color). The VE882 / VE892 can also extend the IR remote control and transfer RS-232 signals (up to 115kbps) in both directions, allowing you to connect serial devices, such as touch screens and barcode scanners.
Page 7
Features Extends the transmission range of HDMI, IR and RS-232 signals using one fiber optic cable Very long distance transmission – up to 600m for VE882, up to 20km for VE892* HDMI (3D, Deep Color), HDCP compatible – signaling rates up to 3.125 Gbits...
Page 8
1 HDMI cable for the source device you will be connecting** 1 HDMI cable for the display device you will be connecting** If you wish to utilize the VE882 / VE892’s high-end serial controller function, you need to purchase an appropriate RS- 232 cable.
Components Top View Component Description Power / Link The LED blinks to indicate that the unit is receiving power. The LED lights to indicate that the fiber optic cable is detected, and communication between the transmitter and receiver is reliable. Front View Component Description...
Rear View Component Description Optical In/Out The fiber optic cable that connects the transmitter and Port* receiver units plugs in here. Power Jack The power adapter cable plugs in here. *The Optical In/Out port’s color varies as follows: VE882T - Blue VE882R - Yellow VE892T - Purple VE892R - White...
Wall Mounting For convenience and flexibility, the VE882 / VE892 can be mounted on the wall. To mount a unit do the following: 1. Using the screws provided in the Mounting Kit, screw the mounting brackets onto the side panels of the unit as shown in the diagram below: Note: 1.
5. Plug the power adapter cable into the power jack on the VE882/VE892. 6. (Optional) Connect your computer or controller system (RS- 232 Port) to the terminal block on the VE882/VE892 to perform serial commands. 7. a. Connect an IR Transmitter/Receiver to the IR port on the VE882T/VE892T.
Page 13
VE882R/VE892R IR Port Serial Device HDMI Display Device VE882T/VE892T HDMI Source Device IR Port - 13 -...
RS-232 Channel Transmission The RS-232 signal transmission flow is shown in the following illustration: Serial Fiber Device CONFIGURATION (Captive screw connectors) From a source device, the RS-232 signal is transmitted (Tx) to the VE882T/VE892T receiving (Rx) unit; the VE882R/VE892R transmits (Tx) signals to the display device (Rx). - 14 -...
3. It is recommended that you use a Single Mode fiber optic cable that conforms to the IEC 60793- 2-50 B1.1 or ITU-T G.652.B specifications. 4. The VE882 supports OM3 optical fiber which can extend the transmission distance up to 300 meters.
