- Page 2 VE882K2 User Manual Compliance Statements FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 VE882K2 User Manual HDMI Trademark Statement The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. RoHS This product is RoHS compliant.
- Page 4 VE882K2 User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988...
- Page 5 VE882K2 User Manual Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com...
- Page 6 Specifications ......... . 17 ATEN Standard Warranty Policy ......19...
- Page 7 VE882K2 User Manual About this Manual This user manual is provided to help you get the most from the VE882K2 HDMI Optical Extender. It covers all aspects of installation, configuration, and operation. An overview of the information found in the manual is provided below.
- Page 8 VE882K2 User Manual Conventions This manual uses the following conventions: Indicates text that you should key in. Monospaced Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt].
- Page 9 3.125 Gbps optical link (for resolutions up to 1080p @ 60 Hz at 24-bit color depth). The VE882K2 can also extend the IR remote control and transfer RS-232 (up to 115 kbps) in both directions, allowing you to connect serial devices such as...
- Page 10 VE882K2 User Manual Features Extends the transmission range of HDMI, IR and RS-232 signals using one fiber optic cable Very long distance transmission—up to 20 km HDMI (3D, Deep Color), HDCP-compatible—signaling rates up to 3.125 Gbits Superior video quality—up to 1080p @ 60 Hz ...
- Page 11 1 HDMI cable for the source device you will be connecting** 1 HDMI cable for the display device you will be connecting** If you wish to utilize the VE882K2’s high-end serial controller function, you need to purchase an appropriate RS-232 cable.
- Page 12 VE882K2 User Manual Supported Video Resolutions The VE882K2 supports the following video resolutions: Resolution Frequency (Hz) 640 × 480 720 × 480 800 × 600 1024 × 852 1280 × 720 1280 × 800 1280 × 1024 1366 × 768 1400 ×...
- Page 13 Chapter 2 Hardware Setup 1. Please review the safety information regarding the placement of this device in Safety Instructions, page 13. 2. Do not power on the VE882K2 until all the necessary hardware is connected. Components VE882TK2 / VE882RK2 Front View...
- Page 14 VE882K2 User Manual VE882TK2 / VE882RK2 Rear View Component Description optical in (VE882RK2) / Connect the optical input port of VE882RK2 and the optical output port of VE882TK2 using a fiber optic optical out (VE882TK2) cable. power jack Plug the supplied power adapter to the power jack.
- Page 15 Chapter 2. Hardware Setup VE882TK2 / VE882RK2 Top View Component Description power & link LED The LED blinks to indicate that the unit is receiving power. The LED lights to indicate that the fiber optic cable is detected, and communication between the transmitter and receiver is reliable.
- Page 16 VE882K2 User Manual Mounting For convenience and flexibility, the VE882TK2 / VE882RK2 can be mounted on the wall. To mount a unit, do the following: 1. Use the screws provided in the mounting it, and screw the mounting brackets onto the side panels of the unit as shown in the diagram below: Note: We recommend that you use M5 x 12 Phillips Type I cross, recessed type screws.
- Page 17 Chapter 2. Hardware Setup Installation Follow the steps below to connect the devices and the VE882TK2 and VE882RK2: Note: 1. Make sure all the equipment you are connecting to the unit is turned off and disconnected from the power source. You must unplug the power cords of any computers that have the Keyboard Power On function.
- Page 18 5. (Optional) Connect your computer or controller system (RS-232 port) to the terminal block on the VE882K2 unit to perform serial commands. Note: The unit supports bi-directional RS-232 bypass transmission. To...
- Page 19 Chapter 2. Hardware Setup RS-232 Channel Transmission The illustration shows an example of the RS-232 transmission flow. VE882TK2 VE882RK2 Hardware / Optical Fiber Software Controller RS-232 RS-232 From a source device, the RS-232 signal is transmitted (Tx) to the VE882TK2 receiving (Rx) unit;...
- Page 20 VE882K2 User Manual This Page Intentionally Left Blank...
- Page 21 Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result.
- Page 22 VE882K2 User Manual Do not attempt to service the device yourself. Refer all servicing to qualified service personnel. If the following conditions occur, unplug the device from the wall outlet and bring it to qualified service personnel for repair.
- Page 23 Appendix Rack Mounting Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack.
- Page 24 VE882K2 User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://support.aten.com For telephone support, see Telephone Support, page iv. North America Email Support support@aten-usa.com Online Technical Troubleshooting http://www.aten-usa.com/support Support Documentation Software Updates...
- Page 25 Appendix Specifications Function VE882RK2 VE882TK2 Video Input Interfaces 1 × HDMI Type A Female (Black) Impedance 100 Ω Max. Distance Video Output Interfaces 1 × HDMI Type A Female (Black) Impedance 100 Ω Max. Distance Video Max. Data Rate 6.75 Gbps 6.75 Gbps (2.25 Gbps Per Lane) (2.25 Gbps Per Lane)
- Page 26 VE882K2 User Manual Function VE882RK2 VE882TK2 Control RS-232 Channel 1 × Terminal Block, 3 pole 1 × Terminal Block, 3 pole (Green) (Green) IR Channel 1 × Mini Stereo Jack Female 1 × Mini Stereo Jack Female (Black); (Black); 30K–56 KHz full range 30K–56 KHz full range...
- Page 27 © Copyright 2024 ATEN® International Co., Ltd. Released: 2024-08-29 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners.
