HDMI Optical Extender
USER MANUAL
VE882 / VE892

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VE882 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATEN VE882

Summary of Contents for ATEN VE882

  • Page 1 HDMI Optical Extender USER MANUAL VE882 / VE892...

  • Page 2: Fcc Information

    FCC Information This is an FCC Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Online Registration

    VE882 / VE892 User Manual Online Registration International http://eservice.aten.com Telephone Support International 886-2-8692-6959 China 86-10-5255-0110 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 United Kingdom 44-8448-158923 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com...

  • Page 4: Package Contents

    ® Copyright © 2013 ATEN International Co., Ltd. Manual Date: 2013-03-05 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -...
  • Page 5 3.125 Gbps optical link (for resolutions up to 1080p@60Hz at 24-bits). The VE882 / VE892 can also extend the IR remote control and transfer RS-232 signals (up to 115kbps) in both directions, allowing you to connect serial devices, such as touch screens and barcode scanners.
  • Page 6 Features Extends the transmission range of HDMI, IR and RS-232 signals using one fiber optic cable* Very long distance transmission – up to 600m for VE882, up to 20km for VE892 HDMI (3D, Deep Color), HDCP compatible – signaling rates up to 3.125 Gbits...
  • Page 7 Contact your dealer to purchase the correct cable sets. If you wish to utilize the VE882 / VE892’s high-end serial controller function, you need to purchase an appropriate RS- 232 cable.

  • Page 8: Front View

    Components Top View Component Description Power / Link The LED blinks to indicate that the unit is receiving power. The LED lights to indicate that the fiber is detected, and communication between the transmitter and receiver is reliable. Front View Component Description HDMI Input/...

  • Page 9: Rear View

    Rear View Component Description Optical IN/ The fiber optic cable that connects the Transmitter and OUT Port* Receiver Units plugs in here. Power Jack The power adapter cable plugs in here. *The Optical IN/OUT port’s color varies as follows: VE882T - Brown VE882R - Yellow VE892T - Purple VE892R - White...

  • Page 10: Wall Mounting

    Wall Mounting For convenience and flexibility, the VE882 / VE892 can be mounted on the wall. To mount a unit do the following: 1. Using the screws provided in the Mounting Kit, screw the mounting brackets into the side panels of the unit as show in the diagram below: Note: 1.

  • Page 11: Installation

    5. Plug the power adapter cable into the power jack on the VE882/VE892. 6. (Optional) Connect your computer or controller system (RS- 232 Port) to the terminal block on the VE882/VE892 to perform serial commands. 7. a. Connect an IR Transmitter/Receiver to the IR port on the VE882T/VE892T.
  • Page 12 VE882R/VE892R IR Port Serial Device HDMI Display Device VE882T/VE892T HDMI Source Device IR Port - 12 -...

  • Page 13: Rs-232 Channel Transmission

    RS-232 Channel Transmission The RS-232 signal transmission flow is shown in the following illustration: Serial Fiber Device CONFIGURATION (Captive screw connectors) From a source device, the RS-232 signal is transmitted (Tx) to the VE882T/VE892T receiving (Rx) unit; the VE882R/VE892R transmits (Tx) signals to the display device (Rx). - 13 -...

  • Page 14: Specifications

    Power 1 x DC jack (Black) Fiber Optics Operating distance* VE892: 20 km with single mode (SM) fiber VE882: 600 m with single mode (SM) fiber Wavelength 1310/1550 nm for SM Data rate Single fiber: 1080p/60Hz (24-bits, 3.125G bps )

This manual is also suitable for:

Ve892
