Summary of Contents for CTC Union ET100/G64
- Page 1 ET100/G64 Synchronous WAN Ethernet Bridge 10/100Base-TX Ethernet over G.703 64K Co-directional...
- Page 3 Neihu Technology Park 8F, No. 60 Zhouzi Street. Neihu District, Taipei, 114 Taiwan ET100/G64 Ethernet WAN Bridge, User Manual Version 1.0 Nov. 4, 2008 Release Version 1.1 Jul. 21, 2009 Update This manual supports the following models: ET100/G64 Ethernet WAN Bridge...
- Page 4 Should the Buyer purchase or use a CTC Union product for any such unintended or unauthorized application, the Buyer shall indemnify and hold CTC...
-
Page 5: Table Of Contents
Table of Contents 1.0 Overview..............................7 1.1 Features ..............................7 1.2 Specifications ............................7 1.3 Functional Block Diagram ........................9 1.4 Unit Detail............................. 10 1.5 Theory of Operation..........................12 1.6 DIP Switch Setting Tables: ........................13 1.6.1 Data Rate Settings:......................... 13 1.6.2 Interface Settings: .......................... - Page 6 Table of Contents This page left blank intentionally.
-
Page 7: Overview
ET100/G64 LAN-WAN Bridge 1.0 Overview The ET100/G64 Network Bridge is a high performance, remote, self-learning Ethernet bridge. Its solid design makes it ideal for cost-sensitive bridging applications, or as a LAN extender or segmenter over G.703 64K Co-directional bit stream type infrastructures. - Page 8 Loop back enable Loop back When the Loop back push-button switch is depressed, Received timing and data are looped back out the Transmit timing and data interfaces. Co-directional Figure 1. ET100/G64 Loop back paths Co-directional Pin Assignment Designation Description RxRing...
-
Page 9: Functional Block Diagram
Ext. clock CONTROLLER Int. clock Clock Generator FILTER SYNC ENGINE SPEED N64K plus 256 MAC Address Table IEEE802.3u I/F Full Duplex Link LED Half Duplex LAN Tx LED Auto-MDIX Phy LAN Rx LED LAN SIDE RJ-45 Figure 2: ET100/G64 Block Diagram... -
Page 10: Unit Detail
ET100/G64 LAN-WAN Bridge 1.4 Unit Detail 1 1 2 2 3 3 4 11 11 5 6 7 8 5 6 7 8 9 10 9 10 Figure 3: ET100/G64 Front Panel Detail Figure 4. ET100/G64 Unit Detail... - Page 11 ET100/G64 LAN-WAN Bridge PWR LED Green on, when external power adapter is plugged in and AC power is supplied to it. G.703 TD LED: Green, on or flashing indicates receiving data on the G.703 co-directional interface. G.703 RD LED: Green, on or flashing indicates transmitting data on the G.703 co-directional interface.
-
Page 12: Theory Of Operation
The ET100/G64 utilizes both Ethernet Bridging and HDLC encapsulation to provide a connection between LANs over bit stream architectures. The LAN side of the ET100/G64 receives an Ethernet packet and examines its destination MAC address. If it knows the MAC is on the local network then it simply drops the packet. -
Page 13: Dip Switch Setting Tables
ET100/G64 LAN-WAN Bridge 1.6 DIP Switch Setting Tables: 1.6.1 Data Rate Settings: The ET100/G64 is designed for a fixed data rate of 64Kbps. SW STATE Function Reserved Table 1: DIP settings for Data Rate. 1.6.2 Interface Settings: SW STATE Function... -
Page 14: Clocking Examples
When this feature is disabled, all frames are passed transparently. In this configuration, the ET100/G64 acts as a repeater. When the filter is enabled, frame destinations are tested against the internal MAC address table. Filtering enabled is the normal selection for Bridging but is usually disabled when connecting to a switching HUB. - Page 15 ET100/G64 LAN-WAN Bridge The next example connects the pair of ET100/G64 bridge units to existing G.703 64K co-directional transmission equipment which already supplies the clock to the tributary equipment. G.703 64K co-directional Transmission Equipment 64K Receive 64K Receive Figure 7: Point to Point, over existing co-directional equipment (recovery clock)
- Page 16 ET100/G64 LAN-WAN Bridge...
- Page 17 CTC Union Technologies Inc Fax:(886)2 27991355 Tel:(886)2 26591021 Attn : Technical Support Department E-mail:techsupport@ctcu.com From Company: Name: Tel: ( Fax:( MODEL: ET100/G64 ACTIVITY: As attached in DIP switch setting table SYS CONFIGURATION: Question...
- Page 18 Technical Inquiry Form MODEL No.: ET100/G64 Please fill in the DIP switches configuration with ' ' marks into the following table. Send it to us by fax, and we will reply to you immediately. Your Setting CTC Suggestion SW NO. DIP...
