Summary of Contents for CTC Union VDTU2R140

  • Page 1 VDSL2 Router with 4-Port Ethernet...
  • Page 2 User Manual Version 1.0 April 2013 (Revised) This document is the current official release manual. Please check CTC Union's website for any updated manual or contact us by E-mail at sales@ctcu.com. Please address any comments for improving this manual or to point out omissions or errors to marketing@ctcu.com. Thank you.

  • Page 3: Table Of Contents

    VDSL2 Router User Manual, Ver. 1.0 Tables of Contents CHAPTER 1 INTRODUCTION ..........................4 ..............................4 EATURES ..............................5 PECIFICATION CHAPTER 2 HARDWARE INSTALLATION ....................... 7 2.1 F ................................. 7 RONT ANEL 2.2 R ................................8 ANEL CHAPTER 3 CONFIGURATION ..........................9 3.1 L ...................................
  • Page 4 VDSL2 Router User Manual, Ver. 1.0 3.8.1 SNTP ..............................43 3.8.2 SNMP ..............................44 3.8.3 Telnet ..............................45 3.9 S ................................46 TATUS 3.9.1 VDSL2 ..............................46 3.9.2 WAN ..............................47 3.9.3 Route ..............................47 3.9.4 DHCP Client ............................48 3.9.5 Switch ..............................

  • Page 5: Chapter 1 Introduction

    User Manual, Ver. 1.0 Chapter 1 Introduction CTC UNION VDSL2 Router is a single-VDSL2-port router with 4 10/100Mbps Ethernet ports. With the latest VDSL2 technology (ITU G.922.3), it delivers the extraordinary bandwidth and supports up to VDSL2 profile 30a; and, it is perfectly suitable for triple play applications (video, voice and data).

  • Page 6: Specification

    VDSL2 Router User Manual, Ver. 1.0 1.2 Specification VDSL2 standards  Compliant with ITU VDSL2 standard G.993.2 Annex A, Annex B and Annex C  Support VDSL2 profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a and 30a  Band plan profile: symmetric (Plan 997) and asymmetric (Plan 998) Management ...
  • Page 7  Power consumption: 9 watts maximum. Temperature: 0~45°C  Humidity: 0%~95%RH (non-condensing)  * CTC UNION reserves the right to change specifications without prior notice. All brand names and trademarks are property of their respective owners. All rights reserved. Page:6...

  • Page 8: Chapter 2 Hardware Installation

    VDSL2 Router User Manual, Ver. 1.0 Chapter 2 Hardware Installation This chapter shows the front panel and how to install the hardware. 2.1 Front Panel Please see the graphic below for the front panel: Front panel can be separated into six parts from left to right: (1) Power (2) System (3) Central Office...

  • Page 9: Rear Panel

    VDSL2 Router User Manual, Ver. 1.0 2.2 Rear Panel The rear panel of VDSL2 Router is where all of the connections are made. Router Connectors Description of VDSL2 DC-IN Power adaptor inlet: Input voltage 12VDC LAN (1,2,3,4) Four Ethernet10/100BaseT auto-sensing and auto-MDI/MDIX for Ethernet ports(RJ-45) PHONE Telephone port (RJ-11)

  • Page 10: Chapter 3 Configuration

    VDSL2 Router User Manual, Ver. 1.0 Chapter 3 Configuration 3.1 Login There is no software required to install in order to access your web controller, and all you need is a web browser. To login your management system, please open any browser, such as, Internet Explorer, Firefox, etc., and go to “http://192.168.1.1”...

  • Page 11: Home

    VDSL2 Router User Manual, Ver. 1.0 The VDSL2 router supports various features. In addition, it sorts all features into 11 sections, as the followings: Home  Return to the main page. Wizard  Quick setup wizard VDSL2  For setting up the details of VDSL2 Network ...
  • Page 12 VDSL2 Router User Manual, Ver. 1.0 3.2 Home Click on “Home” on the menu section to load the main page. The real-time status of VDSL2 router will be showed the main page. Page: 11...
  • Page 13 VDSL2 Router User Manual, Ver. 1.0 3.3 Wizard “Wizard” is the quick setup function, which will guide the users to setup the VDSL2 router step by step. Step 1. Choose VDSL2 mode: CPE or CO. Then, click “Next” to continue setting up the VDSL2 router.
  • Page 14 VDSL2 Router User Manual, Ver. 1.0 Click on “Apply” to save the setups. Click on “Previous” to go back the previous step. As a Router modem: Choose “Router” in step 2 and click on “Next” to go to step 3. Step 3.
  • Page 15 VDSL2 Router User Manual, Ver. 1.0 While applying the new setups, you should be able to see the following image. When the setup process is complete, you will be able to see the following image. Page:14...
  • Page 16 VDSL2 Router User Manual, Ver. 1.0 3.4 VDSL2 “VDSL2” function allows you to setup the detailed VDSL2 parameters. CPE Mode:  Operating Mode:  CPE (RT) or CO (COT)  You are able to change the operating mode as a CPE device or a CO device here.
  • Page 17 VDSL2 Router User Manual, Ver. 1.0 xDSL Recommendation(s) Carrier Set Designation G.992.1 – Annex A, G.992.2 – Annex A/B, G.992.3 – Annex A/I/L, G.992.4 – Annex A/I G.992.5 – Annex A/I G.992.1 – Annex B, G.992.3 – Annex B G.992.5 – Annex B G.993.1 –...
  • Page 18 VDSL2 Router User Manual, Ver. 1.0  Adaptation Length:  Default value: 3800  Range: 1500 ~ 3900  Band Profile:  Default value: A_R_POTS_D-32_EU-32  Options: Annex Type Options A_R_POTS_D-32_EU-32 Annex A A_R_POTS_D-64_EU-64 B8-1_998-M1x-A B8-2_998-M1x-B B8-3_998-M1x-NUS0 B7-1_997-M1c-A-7 B8-4_998-M2x-A B7-2_997-M1x-M-8 B8-5_998-M2x-M B7-3_997-M1x-M B8-6_998-M2x-B...
  • Page 19 VDSL2 Router User Manual, Ver. 1.0  MIB Parameters:  This section is to setup other VDSL2 parameters for both Upstream and Downstream.  Target SNR:  Default value: 6dB  Range: 6dB to 24dB  This option is to set up the target SNR value, which means the SNR value of the connection will be equal to higher than the target SNR value.
  • Page 20 VDSL2 Router User Manual, Ver. 1.0 specified value. DynamicRa Dynamic rate-adaptation during the initialization process as well as during SHOWTIME. Rate Adaptation Mode and Definition The following setups are for defining the details of “Rate Adaptation Mode” for Upstream and Downstream. ...

  • Page 21: Hostname

    VDSL2 Router User Manual, Ver. 1.0 3.5 Network “Network” section is for setting up the necessary parameters for a network interface. The details of “Network” function includes:  Hostname  Interface   DHCP 3.5.1 Hostname “Hostname” is the name of the device for others to identify the device in a computer network.
  • Page 22 VDSL2 Router User Manual, Ver. 1.0 3.5.2 Interface “Interface” section is for defining LAN interface and WAN interface. In this section, you are allowed to reset the operation mode of the VDSL2 router as “Bridge” or “Router”. The followings are the details you are allowed to modify in “Interface” section. ...
  • Page 23 VDSL2 Router User Manual, Ver. 1.0 3.5.3 The VDSL2 router allows users to save two DNS servers as “Primary Server” and “Secondary Server”. 3.5.4 DHCP The VDSL2 router supports DHCP server only. You are allowed to enable or disable DHCP function of the router. The followings are the details of DHCP function. ...

  • Page 24: Advance

    VDSL2 Router User Manual, Ver. 1.0 3.6 Advance In “Switch” section, you are allowed to setup further details, such as the followings:  Switch  Bandwidth  VLAN  Route   DDNS  IGMP 3.6.1 Switch You are able to change the individual duplex mode for each Ethernet port in VDSL2 router.

  • Page 25: Bandwidth

    VDSL2 Router User Manual, Ver. 1.0 3.6.2 Bandwidth “Bandwidth” section is where you can setup the bandwidth control for each Ethernet port.  Mode: Off or On  TX N value  0: no limit  1 ~ 3124: the value of N ...

  • Page 26: Tag-Base

    VDSL2 Router User Manual, Ver. 1.0 3.6.3.1 Tag-Base There are 16 rules allowed in “Tag-Base” VLAN. For each policy, you can choose which LAN port or WAN port should be included in the rule by clicking on the corresponding checkboxes. Check the checkbox to choose the group...
  • Page 27 VDSL2 Router User Manual, Ver. 1.0 according to the corresponding port and check whether there is any VLAN rule matched with this PVID. If yes, allow the access; otherwise, deny the access.  TAG Mode:  Un-tag: remove the VLAN ID of an egress packet. ...

  • Page 28: Port-Base

    VDSL2 Router User Manual, Ver. 1.0 3.6.3.2 Port-Base You are able to setup maximum of 6 VLAN rules in “Port-Base” mode.  TPID (Tag Protocol Identifier)  Default value: 33024 (0x8100)  Range: 33024 ~ 37120 (0x8100 ~ 0x9100) Note: The value of TPID is in decimal format. ...

  • Page 29: Route

    VDSL2 Router User Manual, Ver. 1.0 3.6.4 Route “Route” function allows you to build up the static routing table. Click on “Append” button to show the detail setups.  Destination IP  Netmask  Gateway  Interface  LAN or WAN Page:28...

  • Page 30: Qos

    VDSL2 Router User Manual, Ver. 1.0 3.6.5 Four popular QoS methods are supported in VDSL2 router.  Port Based Priority  VLAN Tag Priority  IP DSCP Priority  TCP UDP Priority You are able to choose which methods you want by clicking on the desired method on “Mode”...
  • Page 31 VDSL2 Router User Manual, Ver. 1.0 3.6.5.1 Port Based Priority “Port Based Priority” method is to assign a priority queue for ingress packets and send out packets based on the priority sequence.  Scheduling Configuration  There are 4 priority queues for Port Based Priority QoS function. Each queue will be assigned with a scheduling method, such as, SP, BE, WRR or WFQ.
  • Page 32 VDSL2 Router User Manual, Ver. 1.0  WRR Configuration  For assigning the weight of each priority queue. (Note: 8 is the highest.)  WFQ Configuration  For assigning the data rate of each priority queue.  Port Based Priority ...
  • Page 33 VDSL2 Router User Manual, Ver. 1.0 3.6.5.2 VLAN Tag Priority “VLAN Tag Priority” will sort all ingress packets according to the priority of VLAN tag and store all the packets into the assigned priority queues. “VLAN Tag Priority” adopts the same setup styles as “Port Based Priority”, except the last setup, “VLAN Tag Priority”.
  • Page 34 VDSL2 Router User Manual, Ver. 1.0 3.6.5.3 IP DSCP Priority “IP DSCP Priority” method is to assign ingress packets with the priority queues based on the DSCP value of IP packet header. “Scheduling Configuration”, “WRR Configuration” and “WFQ Configuration” are same as these in “Port Based Priority”. ...
  • Page 35 VDSL2 Router User Manual, Ver. 1.0 3.6.5.4 TCP UDP Priority “TCP UDP Priority” method is to assign the priority queue according to the port number. Same as “Port Based Priority”, you need to setup “Scheduling Configuration”, “WRR Configuration” and “WFQ Configuration” first. Then, the following three setup sections are the major setup for “TCP UDP Priority”...
  • Page 36 VDSL2 Router User Manual, Ver. 1.0  Pre-define Logical Port Number  4 rules can be set in this section.  Mode  Disable: disable the rule  Enable: enable the rule  Port: the port number  Queue: the priority queue ...

  • Page 37: Ddns

    VDSL2 Router User Manual, Ver. 1.0 3.6.6 DDNS “DDNS” (Dynamic DNS) is support in VDSL2 router. This function allows you to update the DNS table among two listed providers.  Mode: Off or On  Provider: the DNS service provider ...

  • Page 38: Security

    VDSL2 Router User Manual, Ver. 1.0 3.7 Security “Security” section allows you to enhance the connection security. The section consists of 3 major functions.  Firewall  MAC Filter  IP Filter 3.7.1 Firewall “Firewall” function includes firewall feature and DoS protection feature. In addition, you are allowed to create 8 security rules.
  • Page 39 VDSL2 Router User Manual, Ver. 1.0  Protection:  DoS Protection  Off (disable DoS protection), Low, Medium, and High Medium High  Invalid TCP Flags  Items in “Low”  Items in both “Low”  Xmas Tree Scan  UDP Netbios Attack and “Medium”...
  • Page 40 VDSL2 Router User Manual, Ver. 1.0  Security Rules (01 ~ 08) Click here to change the other rule set.  Mode  Off: disable the security rule.  On: enable the security rule.  Action  Filter: to setup the rule as a filter, therefore, the option is associated with “Source IP”...
  • Page 41 VDSL2 Router User Manual, Ver. 1.0 3.7.2 MAC Filter “MAC Filter” is where you are able to setup an access list based on MAC addresses.  Mode  Off: to disable MAC Filter function  On: to enable MAC Filter function ...

  • Page 42: Ip Filter

    VDSL2 Router User Manual, Ver. 1.0 3.7.3 IP Filter “IP Filter” function will deny or allow different types, such as, ICMP, TCP and UDP, of packets from the range of assigned IP addresses.  Mode:  Off: to disable IP filter function ...
  • Page 43 VDSL2 Router User Manual, Ver. 1.0  Entry 01 ~ Entry 16  Mode  Off: to disable the entry  On: to enable the entry  Action  Deny  Permit  Protocol  All, ICMP, TCP, and UDP ...

  • Page 44: Management

    VDSL2 Router User Manual, Ver. 1.0 3.8 Management The VDSL2 router supports 3 remote management features:  SNTP  SNMP  Telnet You are able to access and manage the router remotely. 3.8.1 SNTP “SNTP” function allows you to setup the web site where you would like to synchronize the time this router modem.
  • Page 45 VDSL2 Router User Manual, Ver. 1.0 3.8.2 SNMP “SNMP” function is to setup the passwords for connecting your SNMP server. By doing so, you are able to monitor this VDSL2 router via SNMP server. (Note: VDSL2 router supports SNMPv2c.)  Mode: Off or On ...

  • Page 46: Telnet

    VDSL2 Router User Manual, Ver. 1.0 3.8.3 Telnet “Telnet” function is to enable the access of telnet. Note: if the mode is “Off”, you will not able to access the VDSL2 router via telnet.  Mode: Off or On  Port: the access port Page: 45...

  • Page 47: Status

    VDSL2 Router User Manual, Ver. 1.0 3.9 Status “Status” section allows you to monitor the status of the router. You are able to check the following status:  VDSL2   Route  DHCP Client  Switch 3.9.1 VDSL2 “VDSL2” function is for monitoring the VDSL2 connection. For CO and CPE modems, there will be different information displayed.

  • Page 48: Route

    VDSL2 Router User Manual, Ver. 1.0 3.9.2 “WAN” page will show the information of WAN interface, such as:  Mode  IP Address  Network Mask  Link (link status) 3.9.3 Route “Route” presents the routing table. You are able to review the status of the routing table.

  • Page 49: Dhcp Client

    VDSL2 Router User Manual, Ver. 1.0 3.9.4 DHCP Client 3.9.5 Switch “Switch” function shows the current status of each Ethernet port. Page:48...

  • Page 50: Information

    VDSL2 Router User Manual, Ver. 1.0 3.10 Information “Information” section presents 2 major information. 1. System 2. System Log 3.10.1 System “System” function shows all the details of the VDSL2 router. (Note: this page is important when you request technical assistance. Please make sure you provide the image of “System”...

  • Page 51: System Log

    VDSL2 Router User Manual, Ver. 1.0 3.10.2 System Log “System Log” presents the important events of the VDSL2 router during its run-time. Page:50...

  • Page 52: Utility

    VDSL2 Router User Manual, Ver. 1.0 3.11 Utility “Utility” section includes the important tools for you manage the VDSL2 router. It includes:  Upgrade  Backup  Restore Page: 51...
  • Page 53 VDSL2 Router User Manual, Ver. 1.0  Default  Ping  Traceroute Page:52...

  • Page 54: Reboot

    VDSL2 Router User Manual, Ver. 1.0 3.12 Reboot “Reboot” function is for rebooting the VDSL2 router without turning off the power supply. Page: 53...
  • Page 55 REVISION HISTORY DATE VERSION CONTENTS 2013/12/13 1.0 December 2013 Change the interface pictures (front panel & rear panel) (Revised) 2014/4/11 Change product photo in web...
