Introduction - Seagate ST2000NX0243 Product Manual

1.0

Introduction

This manual describes the functional, mechanical and interface specifications for the following
®
Seagate Enterprise Capacity 2.5 HDD v3 SATA model drives:
Sector Size
4096N
512E
512N
These drives provide the following key features:
• 7200 RPM spindle speed.
• 128 MB data buffer.
• PowerChoice™ for selectable power savings
• Top Cover Attached motor for excellent vibration tolerance
• High instantaneous (burst) data-transfer rates (up to 600MB per second).
• Perpendicular recording technology provides the drives with increased areal density.
• State-of-the-art cache and on-the-fly error-correction algorithms.
• Native Command Queuing with command ordering to increase performance in demanding applications.
• Full-track multiple-sector transfer capability without local processor intervention.
• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• Worldwide Name (WWN) capability uniquely identifies the drive.
Seagate recommends validating the configuration with the selected HBA/RAID
Note
controller manufacturer to ensure use of full capacity is supported.
Previous generations of Seagate Self-Encrypting Drive models were called Full
Disk Encryption (FDE) models before a differentiation between drive-based
Note
encryption and other forms of encryption was necessary
The Self-Encrypting Drive models indicated on the cover of this product manual
have provisions for "Security of Data at Rest" based on the standards defined by
Note
the Trusted Computing Group (see www.trustedcomputinggroup.org).
Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D
Standard models
ST2000NX0243
ST1000NX0303
ST2000NX0253
ST1000NX0313
ST2000NX0403
ST1000NX0423
Self-Encrypting Drive
(SED) models
ST2000NX0283
ST1000NX0343
ST2000NX0303
ST1000NX0353
6
