- Page 1 Product Manual Standard models ST2000LV000 ST1000LV000 100813751, Rev. A December 2016...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools and 3D Defense System are either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 Mounting Dimensions (for 2-disk models) ............. . 20 Seagate SkyHawk Product Manual, Rev. A...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate SkyHawk Product Manual, Rev. A... -
Page 6: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® SkyHawk™ model drives: Standard models ST2000LV000 ST1000LV000 These drives provide the following key features: • 1000 Gs non-operating shock and 400 Gs of operating shock. • 128MB buffer. -
Page 7: Drive Specifications
–304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, non-operating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) (below mean sea level, max) Operational Shock 400 Gs at 2 ms max Seagate SkyHawk Product Manual, Rev. A... -
Page 8: Formatted Capacity
One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. Formatted Capacity... -
Page 9: Physical Organization
(such as track-to-track and average), are expected to meet the noted values. However, due Note to the manner in which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may produce results that vary from these specifications. Seagate SkyHawk Product Manual, Rev. A... -
Page 10: Start/Stop Times
+5V input average (25° C) Spinup (max) 1.00A Write average 1.70W 1.80W Read average 1.60W 1.70W Idle, low power mode 0.45W 0.50W Standby 0.13W Sleep 0.13W Standby power is measured at steady state (after 200ms from transition) Seagate SkyHawk Product Manual, Rev. A... - Page 11 Drive Specifications 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure 1 Figure Figure 1 Typical 1D - 5V Startup and Operation Current Profile Seagate SkyHawk Product Manual, Rev. A...
- Page 12 Drive Specifications Figure 2 Typical 2D - 5V Startup and Operation Current Profile Seagate SkyHawk Product Manual, Rev. A...
-
Page 13: Conducted Noise
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to standby mode. In both Idle and standby mode, the drive accepts all commands and returns to active mode when disk access is necessary. Seagate SkyHawk Product Manual, Rev. A... -
Page 14: Environmental Specifications
-304.8m to 12,192m Altitude (-1000ft to 10,000ft) (-1000ft to 40,000ft) Seagate does not recommend operating at sustained case temperatures above 60°C. Note Operating at higher temperatures will reduce useful life of the product. The recommended storage period: • 1 year under controlled conditions of 34°C 90%RH or less Note •... -
Page 15: Vibration
Test for prominent discrete tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 16: Electromagnetic Immunity
From this page, click on the “Is my Drive under Warranty” link. The following are required to be provided: the drive serial number, model number (or part number) and country of purchase. The system will dis- play the warranty information for the drive. Seagate SkyHawk Product Manual, Rev. A... -
Page 17: Agency Certification
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. -
Page 18: Environmental Protection
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 19: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as shown in Figure Figure 3 Attaching SATA Cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. SkyHawk drives support latching SATA connectors. Seagate SkyHawk Product Manual, Rev. A... -
Page 20: Drive Mounting
(14.000) 2X M3 X 0.5-6H 2X (3.000) MOUNTING HOLES: BOTH SIDES 7.000 0.200 BOTH SIDES MIN 3MM FULL THD 3.505+.075-.3X90 (90.600) (4.070) (14.000) BASE (61.720) 4X M3 X 0.5-6H MIN 2.5MM FULL THD 3.505+.075-.3X90 Seagate SkyHawk Product Manual, Rev. A... - Page 21 Mounting Dimensions (for 2-disk models) 0.20 100.35 0.25 (13.430) 69.850 0.250 22.450 16.520 2.499 1.270 7.949 1.270 (90.600) (14.000) BASE 2X M3 X 0.5-6H 2X (3.000) BOTH SIDES 7.000 0.200 MOUNTING HOLES: BOTH SIDES 3.505 +.075 -.3 X90 Seagate SkyHawk Product Manual, Rev. A...
-
Page 22: Serial Ata (Sata) Interface
• the signal pins and the rest of the power pins. There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. All used voltage pins (V ) must be terminated. Seagate SkyHawk Product Manual, Rev. A... -
Page 23: Supported Ata Commands
Set Max Features Password: register as defined to the right. Lock: Unlock: Freeze Lock: Set Max Address Ext Set Multiple Mode S.M.A.R.T. Disable Operations B0h/D9h S.M.A.R.T. Enable/Disable Autosave B0h/D2h S.M.A.R.T. Enable Operations B0h/D8h Seagate SkyHawk Product Manual, Rev. A... - Page 24 Write Sectors Extended ATA-standard power-management commands Check Power Mode Idle Idle Immediate Sleep Standby Standby Immediate ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare Security Erase Unit Security Freeze Lock Security Disable Password Seagate SkyHawk Product Manual, Rev. A...
-
Page 25: Identify Device Command
The maximum value that shall be placed in this field is 0FFFFFFFh. The 0FFFFFFFh value applies to all capacities over 137GB (see Section 2.1, Formatted Capacity for related information). Retired 0000 Multiword DMA active and modes supported (see note following this table) xx07 Seagate SkyHawk Product Manual, Rev. A... - Page 26 These words are required for drives that support the 48-bit addressing feature. Maximum value: 0000FFFFFFFFFFFFh. Streaming Transfer Time - PIO 0000 Reserved 0000 Physical sector size / Logical sector size 6003 Seagate SkyHawk Product Manual, Rev. A...
- Page 27 160–221 ATA-reserved 0000 Transport major version number 101F 223–254 ATA-reserved 0000 Integrity word xxA5 See the bit descriptions below for words 63, 88 and 93 of the Identify Drive data. (on next page) Note Seagate SkyHawk Product Manual, Rev. A...
- Page 28 Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Word 93 1 = 80-conductor cable detected, CBLID above VIH 0 = 40-conductor cable detected, CBLID below VIL Seagate SkyHawk Product Manual, Rev. A...
-
Page 29: Set Features Command
Disable the Free Fall Protection feature (41 above enables the Free Fall Protection feature) Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above Note Seagate SkyHawk Product Manual, Rev. A... -
Page 30: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate SkyHawk Product Manual, Rev. A... - Page 31 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100813751, Rev. A...
