Summary of Contents for Seagate BARRACUDA PRO ST8000DM008
- Page 1 SATA Product Manual Standard 512E model ST8000DM008 ST6000DM006 ST4000DM008 ST2000DM012 100844557, Rev. A Gen. 10 December 2018...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 36 Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 6: Introduction
• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability. • Worldwide Name (WWN) capability uniquely identifies the drive. Seagate recommends validating the configuration with the selected HBA/ Note RAID controller manufacturer to ensure use of full capacity is supported. -
Page 7: About The Serial Ata Interface
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 8: Drive Specifications
Operating temperature 60°C Operating temperature 20°C (operating) Temperature gradient (°C per hour max) 30°C (nonoperating) 5% to 95% (operating) Relative humidity 5% to 95% (nonoperating) Relative humidity gradient 30% per hour max Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 9 One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. * See Section 2.10, "Reliability" for rated MTBF device operating condition requirements. Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 10: Formatted Capacity
220 (230 MB/s max) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 23/30 Standby to Ready (sec) (typ/max) 23/30 Ready to spindle stop (sec) (max) Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 11: Power Specifications
Typical DC 0.71 0.538 9.95 Maximum DC 0.711 0.538 Maximum DC (peak) 1.30 1.824 Operating current (sequential write 64K16Q) Typical DC 0.608 0.536 9.40 Maximum DC 0.61 0.536 Maximum DC (peak) 0.739 1.824 Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 12 Maximum DC 0.629 0.394 Maximum DC (peak) 0.732 0.619 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate BarraCuda Pro SATA Product Manual, Rev. A...
- Page 13 Maximum DC 0.635 0.304 Maximum DC (peak) 0.742 1.767 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate BarraCuda Pro SATA Product Manual, Rev. A...
- Page 14 2.5.1.1 Typical current profiles Figure 1. 8TB & 6TB Typical 12V startup and operation current profile Figure 2. 4TB Typical 12V startup and operation current profile Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 15: Conducted Noise
• Using 5V power, the drive is expected to operate with a maximum of 100mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note 2.5.3 Voltage tolerance Voltage tolerance (including noise): 5V +10/ -5% 12V ± 10% Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 16: Extended Power Conditions - Powerchoicetm
• Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T. Read Data Reports • Attribute 192 - Emergency Retract Count • Attribute 193 - Load/Unload Cycle Count Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 17 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 18: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. 2.6.2 Humidity The values below assume that no condensation on the drive occurs. -
Page 19: Shock
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 10–500 Hz 5.0 Grms ref Linear Random Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 20: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 21: Reliability
From this page, click on the “Is my Drive under Warranty” link. The following are required to be provided: the drive serial number, model number (or part number) and country of purchase. The system will display the warranty information for the drive. Preventive maintenance None required. Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 22: Agency And Safety Certifications
Seagate drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with all relevant regulatory requirements and standards for the drives, Seagate cannot guarantee that all system-level products into which the drives are installed comply with all regulatory requirements and standards applicable to the system-level products. The drive is designed for operation inside a properly designed system (e.g., enclosure designed for the drive), with properly shielded I/O cable (if... -
Page 23: Morocco Commodity Mark
2.11.7 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 24: Environmental Protection
2.12.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. The RoHS2 restricts the use of certain hazardous substances such as Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ether (PBDE), BisBis(2-Ethylhexyl) phthalate (DEHP), Benzyl butyl phthalate (BBP), Dibutyl phthalate (DBP), and Diisobutyl phthalate (DIBP) in electrical and electronic equipment (EEE). -
Page 25: Taiwan Requirements - Taiwan Rohs
The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives. Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 26: Reference Documents
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 27: Configuring And Mounting The Drive
• Use only 6-32 UNC mounting screws. • The screws should be inserted no more than 0.140 in (3.56mm) into the bottom or side mounting holes. • Do not overtighten the mounting screws (maximum torque: 6 in-lb). Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 28: Mechanical Specifications
C L OF DRIVE 2.000 .138±.015 1.028 MAX [26.10MM] Figure 5. Mounting configuration dimensions 5-disk models Note The image is for mechanical dimension reference only and may not represent the actual drive. Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 29 C L OF DRIVE .138±.015 2.000 1.028 MAX 26.10 MM Mounting configuration dimensions 2 and 3-disk models Note The image is for mechanical dimension reference only and may not represent the actual drive. Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 30: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane config- uration. All used voltage pins (V ) must be terminated. Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 31: Supported Ata Commands
/ 0014 Sanitize Device - Freeze Lock Ext / 0020 Sanitize Device - Status Ext / 0000 Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 32 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 33: Identify Device Command
Minimum multiword DMA transfer cycle time per word (120 ns) 0078 Recommended multiword DMA transfer cycle time per word (120 ns) 0078 Minimum PIO cycle time without IORDY flow control (120 ns) 0078 Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 34 NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. 112–118 ATA-reserved 0000 Commands and feature sets supported 43DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx 160–205 ATA-reserved 0000 Seagate BarraCuda Pro SATA Product Manual, Rev. A...
- Page 35 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate BarraCuda Pro SATA Product Manual, Rev. A...
-
Page 36: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate BarraCuda Pro SATA Product Manual, Rev. A... -
Page 37: Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate BarraCuda Pro SATA Product Manual, Rev. A... - Page 38 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100844557, Rev. A...
